Ultra Thin Foldable LED Screen P8.9mm 3000cd/㎡ Outdoor / Indoor Lightweight Display

Ultra Thin Foldable LED Screen P8.9mm 3000cd/㎡ Outdoor / Indoor Lightweight Display

Ultra Thin Foldable LED Screen P8.9mm 3000cd/㎡ Outdoor / Indoor Lightweight Display
Ultra Thin Foldable LED Screen P8.9mm 3000cd/㎡ Outdoor / Indoor Lightweight Display Ultra Thin Foldable LED Screen P8.9mm 3000cd/㎡ Outdoor / Indoor Lightweight Display Ultra Thin Foldable LED Screen P8.9mm 3000cd/㎡ Outdoor / Indoor Lightweight Display

Large Image :  Ultra Thin Foldable LED Screen P8.9mm 3000cd/㎡ Outdoor / Indoor Lightweight Display

Product Details:
Place of Origin: China
Brand Name: 3Cinno
Certification: CE/ROHS/FCC/SGS
Model Number: FL-8.928
Payment & Shipping Terms:
Minimum Order Quantity: 1sqm
Price: negotiation
Packaging Details: Flight case / Wooden box
Delivery Time: 15~25 working days after received your payment
Payment Terms: T/T
Supply Ability: 2,000square meters per month
Detailed Product Description
Pixel Pitch: P8.928 Mm LED Lamp: 3in1 SMD
Brightness: >3000 Nits Refresh Rate: >1800 Hz
Material: Plastic Curve/Circle: Available
Installation: Hanging Panel Size: 1000*1000mm / 1000*2000mm / Customized
High Light:

indoor LED screen

,

outdoor full color LED display

Ultra Thin Foldable LED Screen P8.9mm 3000cd/㎡ Outdoor / Indoor Lightweight Display



Main Feature:



Foldable :  250*250mm module with ultra-thin thickness less than 20mm make the screen

foldable , greatly save much transportation cost and space for installation and storage.



Ultra-thin :  Less than 20mm thickness make screen extremely slim, which requires very small

space for installation and storage.



Low heat :  With good heat conduction design , there isn’t much heat occurred for the screen.



Irregular:    Foldable and ultra-slim structure could create many irregular shape such as 360°circle,

wave, column, stair etc.



Fast :       Fast and easy to install and dismantle with tool-free and modular design





Application:



Perfectly used for outdoor/indoor concerts, cooperating events, TV studio & Films, stage, live show, etc.





Specification:



Flexible Concert LED Display Unit FL-8
Pixel pitch mm 8.928
Pixel configuration 3-in-1 SMD
Viewing angle(H/V) degree 160/160
Resolution per module pixels 28×28
Brightness cd/㎡ 3000
Color temperature k 8000
Brightness/color consistency <97% / Within±0.003 Cx,Cy
Gray scale 4096
Refresh rate Hz ≥1800
Processing bit/color 12
Colors billion 68
Operating power VAC,Hz 100-240,50/60
Power consumption(max/ave) W/sqm 600/300
Working temperature ﹣20 ~45
Working humidity RH 10%~90%
Control System Linsn / Nova
Source compatibility with VP CVBS,YUV, DVI,VGA,S-Video,HDMI,SDI,HDSDI,etc.
Life time Hrs 85,000
Size(W×H×D)  mm/module 250×250×18
Screen unit size(W×H)  mm 1000×1000 / 1000x2000 / customized
Frame material   Plastic
Weight kg/module 1
Weight lbs 2
Serviceability Rear
Installation Hanging
Curve Available, no limit
Serviceability Rear
IP rating IP65
Hanging beam   1m / 1.5m
Package   Flight case





After-sale service:



1.Free technician training.

2.Products usage tracking.

3.Customer satisfaction investigation.

4. Repair service;

5. Complaint response does not exceed 24 hours; maintenance guidance and problem solution

supplied within 48 hours.

6. Full set of documents free of charge including installation guidance, software operation manual,

maintenance manual and control system software CD and so on.

7. On-site service for important projects, such as live shows, celebrations, and so on.





Module size:

Ultra Thin Foldable LED Screen P8.9mm 3000cd/㎡ Outdoor / Indoor Lightweight Display 0



System Diagram:



Ultra Thin Foldable LED Screen P8.9mm 3000cd/㎡ Outdoor / Indoor Lightweight Display 1



Flight Case for package:



Ultra Thin Foldable LED Screen P8.9mm 3000cd/㎡ Outdoor / Indoor Lightweight Display 2
