P10 outdoor energy saving led display:
1, Using Low -power -driven high brightness leds, energy saving ≥ 20%
2, Using high PFC power supply,energy saving≥15%
Traditional AC switching power supply / DC power conversion rates are usually only up to 65 %, while using PFC function switching power supply, AC / DC power conversion rates are usually up to 80% or more
3, Using a series of temperature control, display and control , light control measures, energy saving≥6%
| Technical Parameters of P10 full color outdoor LED display | |
| Usage | Outdoor |
| Pitch(mm) | 10 |
| Pixel Constitute | 1R1G1B |
| LED--Opto+Silan | R:λd(625-630nm) G:λd(522.5-525nm) B:λd(467.5-470nm) R:Ⅳ(450-500mcd) G:Ⅳ(1600-1800mcd) G:Ⅳ(350-400mcd) |
| Pixel Density(dots/㎡) | 10000 |
| Module Size(mm) | 160*160 |
| Module Resolution | 16*16 |
| Recommended Minimum Viewing Distance(m) | >=10 |
| Viewing Angle(°C) | V60, H120 |
| Average Power Consumption | 150W/㎡ |
| Brightness (white balance) | 6000cd/㎡ |
| Size of cabinet(mm) | 640*640*120 |
| Weight of cabinet | 60kg/㎡ |
| Cabinet pixels(dot) | 64*64 |
| Frame frequency | ≥60Hz |
| Refresh rate | ≥2000Hz |
| Grey color | ≥16.7M |
| Brightness adjustment | 256 grade manual, 8 grade automatic |
| Average NO failure time | 5000 hours |
| Life span | 100000 hours |
| Working temperature | -30 °C ～+60°C |
| Driving Voltage | 5VDC |
| Working Voltage | 110 to 220VDC |
| Scan Mode | 1/4 |
| Display Function | Video, Animation, Graphics, other |
| Operating system | Windows (2000/XP/Vista) |
| Control distance | CAT5 cable:<100 m; Single fiber:<10 km |
