P20 Full Color Operating System Windows 2000 Stadium Outdoor LED Display

P20 Full Color Operating System Windows 2000 Stadium Outdoor LED Display

P20 Full Color Operating System Windows 2000 Stadium Outdoor LED Display
P20 Full Color Operating System Windows 2000 Stadium Outdoor LED Display

Large Image :  P20 Full Color Operating System Windows 2000 Stadium Outdoor LED Display

Product Details:
Place of Origin: CHINA
Brand Name: HANTANG
Certification: CE,ROHS,C-TICK,ISO
Model Number: HTGJ-OF20
Payment & Shipping Terms:
Minimum Order Quantity: N/A
Price: N/A
Packaging Details: Carton/Plywood case/Airfreight case
Delivery Time: 15~18days
Payment Terms: 30%before producing,the balance before shipping
Supply Ability: 10000sq.m/month
Contact Now
Detailed Product Description
Highlight:

outdoor led sign

P20 Full Color Operating System Windows 2000 Stadium Outdoor LED Display

Features.
1. Vivid pictures
2. Big viewing angle distance
3. Relative low price
4.Two years warranty


Technical Parameters of P20 full color outdoor LED Display
Usage  Outdoor
Pitch(mm) 20
Pixel Constitute 2R1G1PB
LED--Opto+Silan R:λd(625-630nm) G:λd(522.5-525nm) B:λd(467.5-470nm) R:Ⅳ(450-500mcd) G:Ⅳ(1600-1800mcd) G:Ⅳ(350-400mcd)
Pixel Density(dots/M2) 2500
Module Size(mm) 320*160
Module Resolution 16*8
Recommended Minimum Viewing Distance(m) >=18
Viewing Angle(°C) V40, H110
Average Power Consumption 500W/M2
Brightness (white balance) 5000cd/M2
Size of cabinet(mm) 1280*960*80
Weight of cabinet 60kg/M2
Cabinet pixels(dot) 64*48
Frame frequency ≥60Hz
Refresh rate ≥360Hz
Grey color ≥16.7M
Brightness adjustment 256 grade manual, 8 grade automatic
Average NO failure time 5000 hours
Life span 100000 hours
Working temperature -30 °C ～+60°C
Driving Voltage 5VDC
Working Voltage 110 to 220VDC
Scan Mode  static
Display Function Video, Animation, Graphics, other
Operating system Windows (2000/XP/Vista)
Control distance CAT5 cable:<100 m; Single fiber:<10 km
