Light Weight P20 Outdoor LED Display With Animation Display Function Average Power Consumption 170W/sqm

Light Weight P20 Outdoor LED Display With Animation Display Function Average Power Consumption 170W/sqm

Light Weight P20 Outdoor LED Display With Animation Display Function Average Power Consumption 170W/sqm
Light Weight P20 Outdoor LED Display With Animation Display Function Average Power Consumption 170W/sqm

Large Image :  Light Weight P20 Outdoor LED Display With Animation Display Function Average Power Consumption 170W/sqm

Product Details:
Place of Origin: CHINA
Brand Name: HANTANG
Certification: CE,RoHS,C-TICK,ISO.
Model Number: HTGJ-OF20
Payment & Shipping Terms:
Minimum Order Quantity: 1 Square Meter/Square Meters module
Price: US $ 800 - 1,000 / Square Meter
Packaging Details: Plywood case/Flight cases etc.
Delivery Time: 10-15 working days.
Payment Terms: 30%before producing,the balance before shipping
Supply Ability: 3000sq.m/month.
Contact Now
Detailed Product Description
Highlight:

led outdoor displays

Lightweight P20 Outdoor LED Display With Animation Display Function



Pixel pitch:10mm,12mm,12.5mm,14mm,16mm,20mm,25mm,31.25mm,37.5mm...

Application :billboard,concerts ,stage, events,stadium,advertising ,train station,shopping center,meeting screen ,airport ,mall...



Features:



1) Price Advantage: we have the best competitive price at the market; also have the same even better quality;

2) Performance Advantage: Best Equality, high consistency, Big viewing angle, can repair each led lamps;

3) Quality advantage: From material to finished product, from design to produce, we control all steps that are the guarantee of the quality and reliability;

4) Service advantage: Better service at same situation, better cooperation at same service.



Specification:

Usage  Outdoor
Pitch(mm) 20
Pixel Constitute 2R1G1B
LED--Opto+Silan R:λd(625-630nm) G:λd(522.5-525nm) B:λd(467.5-470nm)
R:(450-500mcd) G:(1600-1800mcd) G:(350-400mcd)
Pixel Density(dots/sqm) 2500
Module Size(mm) 320*160
Module Resolution 16*8
Recommended Minimum Viewing Distance(m) ≥20
Viewing Angle(°C) V60, H120
Average Power Consumption 170W/sqm
Brightness (white balance) ≥6500cd/sqm
Size of cabinet(mm) 1280*960*80
Weight of cabinet 60kg/sqm
Cabinet pixels(dot) 64*48
Frame frequency ≥60Hz
Refresh rate ≥2000Hz
Grey color ≥16.7M
Brightness adjustment 256 grade manual, 8 grade automatic
Average NO failure time 5000 hours
Life span 100000 hours
Working temperature -30 °C ～+60°C
Driving Voltage 5VDC
Working Voltage 110 to 220VDC
Scan Mode  static
Display Function Video, Animation, Graphics, other
Operating system Windows (2000/XP/Vista)
Control distance CAT5 cable:<100 m; Single fiber:<10 km
