Hongkong soundboss P12 Outdoor LED Display Screen for Advertising and publicity

Large Image : Hongkong soundboss P12 Outdoor LED Display Screen for Advertising and publicity

Product Details:

Place of Origin:	Shenzhen China
Brand Name:	S&B
Certification:	CE, RoHS, CCC
Model Number:	SBO-P12
Warranty:	36 months

Payment & Shipping Terms:

Minimum Order Quantity:	1 Piece/Pieces
Packaging Details:	Plywood case; flight case
Delivery Time:	10~20 days
Payment Terms:	T/T
Supply Ability:	5000sq.meter / Month

Contact Now

Detailed Product Description

High Light:

outdoor full color led display

smd led display

Hongkong sounboss P12 Outdoor LED Display Screen for Advertising and publicity

2011 Asian cup LED supplier

1. 36 months warranty. And life long free tech-support

2. CE and RoHS approval

3. Front accessible maintenance

4.Excellent contrast ratio, high definition

5. High brightness and perfect uniformity

6.Waterproof IP65

7. Available models: P8, P10, P12, P16, ect.

Application:

Our products have been widely used in venues such as banks, stock exchange centers, schools, telecommunications, customs, stadiums, studio, shopping malls, railways, airports, harbors, city squares, courts, schools, restaurants etc;

Advantage:

1. High Contrast ratio: 4000:1

This is a very high level to ensure a vivid image of our LED display screen system.

3. First-class LED chip:

Supplied by high strictly selected SMD3535 LED

4. Clear vivid image quality:

Perfect color blending and comfortable visual effect

5. Easy Installation & operation:

Slim and light LED panel, user friendly software for an easy interface to operate the LED system

6. Easy maintenance:

Front and rear cabinet access maintenance

SBO-P12SMD (Pitch 12mm outdoor full color)
Pixel structure	1R1G1B, 3in1
Pixel pitch	12mm
Pixel density	6, 944 dots/㎡
Luminance	6, 500cd/㎡
Module dimension	192mm(W) * 192mm(H)
Module resolution	16 pixel(W) * 16 pixel mm(H)
Cabinet dimension	960 * 768mm
Cabinet resolution	80 * 64
Cabinet area	0.737 sq. meter
Optimal visual distance	>10m
Visual angel	140 / 140 degree (H/V)
Max power consumption	≤960w / ㎡
Average power consumption	≤500w / ㎡
Brightness adjustment	Adjust according to the environment
Brightness adjustment	brightness software (0%-100%adjustable)
Gray scale	point by point 4096 gray grade levels of
Gray scale	each color, 16 bits γ correction available
Drive mode	1/4 dynamic scan, constant current
Frame frequency	≥60HZ
Refresh frequency	≥1000HZ
Input voltage	AC 90~260 volts
Operation temperature	﹣40℃~ +65℃
Operation humidity	10％～90％
Input signal	S-video, RF, RGB, Yuv, YC, composite…
Control system	DVI card + master control card + receiver card
MTBF	>5000 hrs
Life span (50% brightness)	100, 000 hrs
Malfunction dot rate	1/10000
Ingress protection rate (Front/ rear)	IP65 / IP54
Cabinet material	Epoxy paint coated, aluminum / iron
Application:	Rental / Permanent installation available
