3 Year Warranty P10 P16 led outdoor display board full colorled billboard advertising

3 year Warranty P10 P16 Advertising Electronic Outdoor LED Display Billboard Full Color

Products characters:

1. High brightness which is adjustable to sufficiently meet the needs of various application environments.

2. The raw material of all of the outdoor products including LED chips, mask, glue and steel cabinets have the ability of enduring high temperature and high humidity, and being
anti-UV, waterproof, anticorrosion and antirust.

3. Every production process is well controlled and all of the electronic components are covered by 2mm Tri-Guard Lacquer to ensure no oxidation, no rusty and no moisture.
Five-Guard Lacquer will be used for special requirements

4. All of the cabinets are tested by flush, shower and soaking, to ensure the waterproof grade in front side to be IP65 . .

5.Display even after long-term use of perfect quality reproduction and enough brightness .

1) Classification of item: P16 1R1G1B
2) Working environment: Outdoor
3) LED type: DIP1R1G1B
4) Pixel composition: 1R1G1B
5) Pixel pitch: 16.0mm
6) Resolution of module: 16*16
7) Pixel density: 3906dots/m2
8) Module size: 256*256mm
9) White balance brightness: ≥3500cd/m2
10) Best view distance: 16~100m
11) Driving mode: static constant current
12) Module max power consumption: 38.4W
13) Max power consumption: 1000W/sqm
14) Resolution of cabinet: 48*48
15) Dimension of cabinet: 768*768mm
16) Weight of cabinet (waterproof): 51kg
17) Viewing angle(H/V): 110°/50°
18) Frame frequency: ≥60Hz
19) Refresh frequency: ≥360Hz
20) Gray scale: ≥16.7M (synchronal)
21) Brightness adjustment mode: R, G, B 256 manual, 8 automatic
22) Operating power source: AC220V ± 10% or AC110V ± 10%
23) Working temperature: -20°C-50°C or -30°C-50°C
24) MTBF: ≥10,000H
25) Lifespan: ≥100,000H

Advantage

• Louvered-face and mask-face panels are avaiable.
• The whole sign is separated into pieces for transportation.
• Modular Design allows the sign to be built in various size.
• LED module is sealed twice for good weather resistance.
• Forced air ventilation and natural heat-dissipation system.
• Easy access from double-layer weather-resistant rear doors.
