| Item Name: | Led Boards For Advertising | LED Type: | SMD2121 |
|---|---|---|---|
| Average Power: | 200-300W/m² | Module Size: | 256mm×128mm |
| Screen Weight: | 40 Kg/m² | Display Color: | 17M~69G Colors |
| High Light: | led advertising displays,perimeter advertising boards |
||
Energy Saving Thin Indoor P4 Led Boards for Advertising Display
Brief Introduction to P4 Indoor Led Light Display Board:
Along with the constant development of the led screen rental market, Shenzhen D-King Photoelectric Technology Co., Ltd. closely follows the market needs and constantly carries out improvement and innovation, and the newly researched and developed P4 indoor transparent led screen with aluminum pulling cabinet which has been exported to many countries and places. In addition, D-King innovated indoor led advertising display signs has become a new favorite in the indoor stage rental market relying on its features as light and thin cabinet, easy assemble and unassembled, beautiful appearance, high popularity, high cost performance and high value.
Main Advantages of P4 Indoor Led Display Signs:
1. High safety: D-King P4 indoor led display signs use low-voltage direct current supply, so that it is very safe.
2. Softness: D-King led display panel uses soft FPC placode which is easy to molding, so that it is very suitable for the requirements of various advertising modeling.
3. Long service life: The normal service life of a led panel display is 800,000-100,000 hours, and even working 24 hours a day, its service life is almost ten years.
4. Energy conservancy and environment protection: Compared with traditional lighting and ornamental lighting, the luminous element of indoor led display is LED. The power of single LED is very low (0.04~0.08W), the effect is too much better. In addition, the materials used for the production led panel is environmentally friendly materials which are recyclable, so that they will not pollute and damage the environment due to large amount of use.
5. Simple installation: The installation of the led display screen is very simple and convenient, and the attaching clamp, trunking, iron wire and iron net can be installed onto various bearing surface. In addition, the indoor led displays are light and thin, even using double faced adhesive tape can fasten it, which is very convenient.
6. Pure color: D-King led panel board uses high brightness paster, so that the color will be pure, soft and free from glare.
Technical Parameters of P4 Indoor Advertising Led Display Board:
| Model | P4 Indoor Advertising Led Display Board |
| Pixel Pitch | 4mm |
| Pixel Composition | 1R1G1B |
| LED Type | SMD2121 |
| Pixel Density | 62500/m² |
| Scanning method | 1/16 |
| Brightness | ≥1600cd/m² |
| Working Voltage | AC110V±10%, 50Hz-60 Hz |
| Average Power | 200-300W/m² |
| Max. Power | 800W/m² |
| Pixel No. on Unit Plate | 64*32 |
| Module Size | 256mm×128mm |
| Level up degree | <1mm |
| Viewable Distance | ≥4m |
| Viewable Angle | Horizontal: 140°, Vertical: 140° |
| Screen Weight | 40kg/m² |
| Driving Method | Constant current |
| Display Color | 17M~69G colors |
| Display Color | Manual/Automatic/Remote |
| Grey Scale | 256~4096 |
| Refresh Frequency | 300 Hz~2440Hz |
| Refresh Frame Frequency | 60Hz |
| Display Content | TV picture, ads, video, live streaming video, picture and words |
| Display Mode | 640×480, 800×600, 1024×768, 1280×960…1920×1200, 2048×640 |
| Control Method | Synchronous, asynchronous, remote and wireless |
| Transmission Distance | 5E cable≤130M Multimode fibre≤500M monomode fibre≤10KM |
| Transmission Distance | ≥72 hours |
| Service Life of Led | 100,000 hours |
| Mean Time Between Failure | ≥10,000 hours |
| Dispersed Incontrollable Point | <0.01% |
| Continuous Incontrollable Point | No |
| Protecting Technology | Waterproof (Front size IP65, back side IP54), dustproof, antisepsis, antistatic, and has such protection functions of over current, short circuit over voltage and low voltage. |
| Temperature of Use Environment | -20℃~+50℃ |
| Moisture of Use Environment | 10%~90% |
| Certifications | CE, ROHS |
Note: The technical parameters are just for reference, please contact us for details.
