Full Color P5 Indoor Advertising LED Display Signs SMD3528 1R1G1B CE , ROHS

Large Image : Full Color P5 Indoor Advertising LED Display Signs SMD3528 1R1G1B CE , ROHS

Product Details:

Place of Origin:	China
Brand Name:	D-King
Certification:	CE, RoHS
Model Number:	Indoor Led Display Signs

Payment & Shipping Terms:

Minimum Order Quantity:	1 SQM
Price:	Negotiable
Packaging Details:	Wooden box or flight case
Delivery Time:	10-20 days
Payment Terms:	T/T, Western Union, L/C, D/A, D/P, MoneyGram
Supply Ability:	4000m²/month

Contact Now

Detailed Product Description

Item Name:	Indoor Led Display Signs	Brightness:	1500cd/m²
Average Power:	300W/m²	Refresh Frame Frequency:	60Hz
Screen Weight:	40 Kg/m²	Display Color:	17M~69G Colors
Highlight:	led advertising displays

Full Color P5 Indoor Advertising LED Display Signs SMD3528 1R1G1B CE , ROHS

Brief Introduction:

P5 indoor mobile led screen uses high-brightness RGB3528 diodes, and the deviation of the wave length range is ±1.5mm, besides, it has such features as wide visual angle, bright and vivid colors, high picture consistency and clear and fine display effect, so that it is suitable for indoor video display top-grade places.

Features:

1. There are SMD 3in1 and SMD 3piece1 for customers to choose from, and we can provide personalized solution for customers according to their actual requirements.

2. The visual angle of the used chip can reach 140° and the vertical angle can reach 80°, and within this range, the pictures will not deform or have color cast no matter seen from any angle.

3. The product PCB board uses large scale integrated circuit design, thus greatly improving the stability of the led display screens.

4. Advanced high-speed SMT technology is used, which solves the high-density heat dissipation problem from the technique.

Technical Parameters of P5 Indoor Led Display Signs:

Model	P5 Indoor Led Display Signs
Pixel Pitch	5mm
Pixel Composition	1R1G1B
LED Type	SMD3528
Pixel Density	40000/m²
Scanning method	1/16
Brightness	≥1500cd/m²
Working Voltage	AC110V±10%, 50Hz-60 Hz
Average Power	300W/m²
Max. Power	1000W/m²
Pixel No. on Unit Plate	64*32
Module Size	320mm×160mm
Level up degree	<1mm
Viewable Distance	≥5m
Viewable Angle	Horizontal: 140°, Vertical: 140°
Screen Weight	40kg/m²
Driving Method	Constant current
Display Color	17M~69G colors
Display Color	Manual/Automatic/Remote
Grey Scale	1024~4096
Refresh Frequency	300 Hz~2440Hz
Refresh Frame Frequency	60Hz
Display Content	TV picture, ads, video, live streaming video, picture and words
Display Mode	640×480, 800×600, 1024×768, 1280×960…1920×1200, 2048×640
Control Method	Synchronous, asynchronous, remote and wireless
Transmission Distance	5E cable≤130M Multimode fibre≤500M monomode fibre≤10KM
Transmission Distance	≥72 hours
Service Life of Led	100,000 hours
Mean Time Between Failure	≥10,000 hours
Dispersed Incontrollable Point	<0.01%
Continuous Incontrollable Point	No
Protecting Technology	Waterproof (Front size IP65, back side IP54), dustproof, antisepsis, antistatic, and has such protection functions of over current, short circuit over voltage and low voltage.
Temperature of Use Environment	-20℃~+50℃
Moisture of Use Environment	10%~90%
Certifications	CE, ROHS
