DIP 1R1G1B Outdoor Screen P10 Advertising LED Display die-casting aluminium constant static
Advertising LED Display Features:
1) With good lightening accordance and no mosaic
2) Led advertising board can play different formats of image files, flash, WAV/MIDI, video signal from TV, video signal from video and other equipment
3) Different video frequency can be changed freely at the same time, and the image can be enlarged and reduced
4) High brightness, and can be adjustable, meets the need of changing requirement of customer in environment
5) Uses real pixels rather than virtual pixels, better viewing effect
Features:
1. Strictly selected LED chip to ensure the long life time and high brightness of LED displays.
2. Hermetic cabinet and filling the whole of imported silica gel, which makes our products waterproof, sun-screen, dustproof, etc.
3. Widely used in advertising, sports, industrial enterprises, transportation, stations, terminals, airports, construction, education system and other public places.
4. Convenient Servicing:Front and rear cabinet access make the maintance work very convenient.
|
Specifications
|
|
Pitch size
|
10mm
|
|
Module size
|
320mm*160mm
|
|
Panel pixel(dots)
|
32*16
|
|
Pixel configuration
|
1Red,1Green,1Blue(SMD 3-in-1)
|
|
LED chip
|
Epistar
|
|
Color scale
|
256-65536grade/10.74 billion colors
|
|
Pixel density
|
10000/square meter
|
|
View angle(H/V)
|
120/60degree
|
|
Brightness
|
≥1200cd/sqm
|
|
View distance
|
5-300m
|
|
Power consumption
|
100-1500W/sqm
|
|
Operating temperature
|
from —25°C to +60°C
|
|
Operating humidity
|
10%--95%RH
|
|
Life time
|
100,000hours
|
|
Frame speed
|
>150frames per second
|
|
Refresh frequency
|
1000Hz
|
|
Control distance
|
100m (without relay),single mode fiber:
20000m,multi mode fiber:500m
|
|
Power
|
110V/220V/380V±15% 50Hz
|
|
operating system
|
Windows98/Me/2000/Xp
|
|
Drive mode
|
constant current driving
|
|
display mode
|
VGA640X480—VGA1600X1024
|
|
IP Grade
|
IP54
|
Advantage :
1. Front maintenance module structure design, modules can be installed and dismantled from front side, any cabinet within this screen is free of assembly and dismantling.
2. Floor led screen can bear 1 ton weight, IP65 weatherproof level.
3. High structure performance: esy connection of each components, modules and HUB card without flat cables, modules and systems without power cable.
4. Cabinet and modules hollow are designed for great heat dissipation performance, high transparency, and high wind resistance level.
5. Easy and Fast: for both installation and dismantling, without any tools, it takes only 10 seconds to assembly, hanging, pile up and fix installation available.
