Die Casting P5 Indoor Hire LED Screen HD Full Color Stage 1R1G1B 3-IN-1 SMD

Large Image : Die Casting P5 Indoor Hire LED Screen HD Full Color Stage 1R1G1B 3-IN-1 SMD

Product Details:

Place of Origin:	Shenzhen ,China
Brand Name:	LanGao
Certification:	CE/ROHS/FCC/UL/ISO/3C
Model Number:	LGP5

Payment & Shipping Terms:

Minimum Order Quantity:	1sqm. / 1 piece
Packaging Details:	Plywood or Flight Case
Delivery Time:	10-20 days
Payment Terms:	T/T ,L/C ,Paypal or

Contact Now

Detailed Product Description

Usage:	Outdoor	Tube Chip Color:	Full Color
Display Function:	Video	Pixels:	5mm
Brightness:	6000 To 8000cd/sqm	Protection Level:	IP65
Led Chip:	Epistar/Slian	RGB:	1R1G1B
Highlight:	hire led screen

Die Casting HD P5 Indoor Rental LED Display Full Color Stage 1R1G1B 3-IN-1 SMD

LED display Application

P5 Indoor Rental LED Display could be used in indoor environment such as municipal mansion,
enterprise hall, show room, cinema, stage, with various real-time signal sources and the SMD
encapsulation technology, its purpose is to play the important news or events or TV program .

1) High and adjustable brightness can meet the demands of the changing requirement of Customer in different environments.
2) No mosaic due to excellent flatness and nice uniformity of light-emitting.
3) Wide viewing angles and the horizontal angle can reach 140° , The images effect will not change largely in the range.
4) High density make the images softer and vivider.
5) Single-lamp maintenance with low cost.
6) Good heat dissipation capability because of the unique design of vent fan (liking shutter).
7) Environmental-friendly and energy-saving.

Pixel Information	Pixel Pitch	5mm
	Pixel Density	40000 Pixels/m2
	Pixel Configuration	1R1G1B
	LED Wavelength	Red: 615 nm - 635 nm
		Green: 520 nm - 535 nm
		Blue: 465 nm - 475 nm
LED Module	Module Size(mm)	160 (Width) × 160 (Height)
LED Module	Module Resolution	32(Width) × 32 (Height)
Cabinet	Cabinet Size(mm)	640 (Width) ×640(Height)
	Cabinet Resolution	128 (Width) × 128 (Height)
	Total QYT Module Per Cabinet	4 (Width) ×4(Height)
	Cabinet Weight	30kg/m2
	Cabinet Material	Die-casting Aluminum LED Display
Power	Input Voltage	100-240V AC, 50/60Hz
	Max Power Consumption	1100 Watt/m2
	Avg. Power Consumption	650 Watt/m2
	Brightness	≥3500cd/m2
	Brightness Uniformity	Luminance Discrepancy < 5%
	Best Viewing Angle	Horizontal:140°,Vertical:70°
	Viewing Distance	5 - 15 meters
Ambint Conditions	Temperature Range	Working:-20deg. to +60deg
	Operating Humidity	10%90%RH
	Ingression Protection Grade	IP30
Processing	Scanning Mode	1/8 scanning
	Refresh Frequency	600-1200HZ, Adjustable(depends on control system)
	Signal Input	DVI, Composite Video for Live Video
	Supported Networking	Through LAN/WAN, RS 232/RS485
	Controller	Linsn or Nova

Advantage

1. Wide application: it can be used for any rental application of stage show: such as main rental led display, side screen, floor screen, arc screen stage design etc.
2. Easy and Fast: for both installation and dismantling, without any tools, it takes only 10 seconds to assembly, hanging, pile up and fix installation available.
3. High structure performance: easy connection of each components, modules and HUB card without flat cables, modules and systems without power cable.
4. Both indoor and outdoor series are compatible, outdoor SMD and DIP screen with IP65 weatherproof level, so it can be used normally in rainy days.
5. Floor led screen can bear 1 ton weight, IP65 weatherproof level.
