Product Details:
Payment & Shipping Terms:
|
| Pixel Pitch: | 2.5mm | LED Lamp: | Black 3-in-1 SMD |
|---|---|---|---|
| Poster Size: | 55" , 71" , 85" | Brightness: | >1200 |
| Refresh Rate: | >480 | Control: | Synchronous / Asynchronous: Wifi,U Disk, Etc. |
| Material: | Aluminum | Installation: | Standing |
| High Light: | advertising digital signage,hd digital signage |
||
P2.5mm LED Digital Signage Poster Advertising Screen in Stations, Malls, Hotels,etc.
Main Feature:
Aluminum frame, stable all-in-one design, mobile use with wheels on the bottom .
1:2 display ratio with luxurious appearance creating best sight experience ,
suitable for high-end advertising
The surface of the screen with a transparent acrylic plate protection prevent scratched
besides getting waterproof and dustproof performance.
Available for WiFi / 3G wireless and wired network, Remote control and monitoring system
Easy operation with a Cat5e net cable to download the programs and one key to start power.
Application:
Pefectly used for advertising as digital signage in Gas station, Bus stop, Shopping mall,etc.
Specification:
| LED Digital Poster Signage | Unit | PO-2.5 | |||
|---|---|---|---|---|---|
| Pixel pitch | mm | 2.5 | |||
| Pixel density | pixels/㎡ | 160,000 | |||
| Pixel configuration | ﹣ | SMD | |||
| Lamp viewing angle(H/V) | degree | 120/120 | |||
| Brightness | cd/㎡ | ≧1200 | |||
| Refresh rate | Hz | ≧480 | |||
| Processing | bit/color | 12 | |||
| Colors | billion | 68.7 | |||
| Module size(W×H) | mm | 160*160 | |||
| Module resolution(W×H) | pixels | 64*64 | |||
| Display resolution (W×H) | pixels | 256*512 | 320*640 | 384*768 | customized |
| Display size(W×H) | mm | 640*1280 | 800*1600 | 960*1920 | |
| Frame size(W×H) | mm | 715*1600 | 875*1932 | 1060*2320 | |
| Frame size | inches | 55" | 71" | 85" | |
| Material | ﹣ | Aluminum | |||
| Color temperature | k | 3200~9300 adjustable | |||
| Brightness uniformity | ﹣ | ≧97% | |||
| Color uniformity | ﹣ | Within±0.003 Cx, Cy | |||
| Operating temperature | ℃ | ﹣20 ~50 | |||
| Operating humidity | RH | 10%~90% | |||
| Operating power | VAC,Hz | 110/220,50/60 | |||
| Power consumption(max/ave) | W/㎡ | 800/260 | |||
| Service access | ﹣ | Rear | |||
| Installation | ﹣ | Standing | |||
| Control mode | ﹣ | Synchronous /Asynchronous:Wifi,U disk, etc. | |||
| Display content | ﹣ | Pictures, video,animation,text,etc. | |||
| IP rating | ﹣ | IP65 front , IP54 back | |||
| Package | Wooden box | ||||
| Certificates | ﹣ | CE,Rohs,FCC | |||
Material Selection :
1)LED: Well-known international brand with small wavelength range , little brightness attenuation ,
good heat dissipation,etc.
2) Driving IC: Famous brands such as, Taiwan MBI, Japanese Toshiba ,etc. To keep good
consistency and avoid the unstable and flickering light and so on.
3) Power supply: Using industrial strength brand power supply which range of voltage fluctuation
is less 5%, high stability.
5) PCB Board: Painting oil to make it anti-moisture, anti-corrosion and anti-damp suitable
for outdoor usage.
