Aluminum Die Casting PH5 LED Full Color Display 640mm x 640 mm Cabinet

Large Image : Aluminum Die Casting PH5 LED Full Color Display 640mm x 640 mm Cabinet

Product Details:

Place of Origin:	China
Brand Name:	Dreamway
Certification:	CE,ROHS
Model Number:	P5

Payment & Shipping Terms:

Minimum Order Quantity:	negotiable
Price:	negotiable
Packaging Details:	Flight case
Delivery Time:	20 days after receiving the deposit
Payment Terms:	T/T
Supply Ability:	2000sq.m/Month

Contact Now

Detailed Product Description

Highlight:	led full color display

Aluminum Die Casting PH5 LED Full Color Display 640mm x 640 mm Cabinet

Quick Detail:

1. 64 by 32 dots each module;
2. 320 by 160 mm module dimension;
3. 640 by 640 mm each cabinet;
4. 128 by 128 pixels per LED box;
5. 2 by 4 pcs LED modules per cabinet;
6. Die-casting aluminum made.

Detail Description:

This type is 1/16 scan constant current, with 64 by 32 dots per LED module;
Each cabinet size is 640 by 640 mm, specially designed and convenient to take;
2 years quality guarantee provided, and lifetime support for maintenance.

Specifications:

Pixel Pitch	5 mm
LED Composition	1R1G1B
LED Encapsulation	SMD3528
Resolution	40,000 dots/sq.m
LED Module Pixel	W 64 × H 32
Module Size	W 320 × H 160 mm
LED Box	Gray
Cabinet Material	Die-cast aluminum
Driving Method	1/16 constant current scanning
Brightness	≥1500 nits/sq.m
Refresh Rate	≥1200Hz
Out of Control Dot Rate	＜0.0001
Earth Leakage Current	＜2mA
MTBF	＞5,000 hours
LED Life Span	＞100,000 hours
Power Source	110V/60HZ and 220V/50HZ interchangeable
Brand	G-Energy
Control Method	Synchronization control with PC
Input Signal	DVI, COMPOSITE VIDEO, S-VIDEO, HDMI
