Product Details:
Payment & Shipping Terms:
|
Model: | P6 | Cabinet Size: | 768 × 576 Mm |
---|---|---|---|
Cabinet Quantity: | 36 Pcs | Thickness: | 95 Mm |
Power Source: | Chuanglian | Voltage: | 220V |
Power Connector: | LINKO / YZK | Control Card: | LINSN |
Highlight: | waterproof led display |
128 x 96 Pixels Indoor LED Screen Rental PH6 Pitch With 1400 Nits LINSN Control
Quick Detail:
1. 27,777 dots/sq.m;
2. SMD3528 LED type;
3. 32 by 32 dots per LED module;
4. 192 by 192 mm module size;
5. 5 m power cable offered;
6. 30 m signal cable provided.
Detail Description:
This type is P6, 1/16 scan, EPISTAR LED chip, SMD3528, 192 by 192 mm;
Different input signals like DVI, VGA, HDMI, S-VIDEO etc could be achieved;
Operation software is LEDStudio, with high refresh rate and stable working environment.
Application:
This is for indoor rental advertising, like shows, concert, wedding ceremony, fair, and so on.
Specifications:
Model |
P 6 |
LED Composition |
1R1G1B |
LED Chip |
EPISTAR |
LED Module Quantity (Per Cabinet) |
W 4 × H 3 = 12 pcs |
LED Module Pixel |
W 32 × H 32 |
LED Module Size |
W 192 × H 192 mm |
LED Cabinet Size |
W 768 × H 576 × D 95 mm |
Material |
Steel rental cabinet with locks and handle |
Driving Mode |
1/16 scan constant current |
Brightness |
≥1400 nits/sq.m |
Refresh Rate |
≥1200Hz |
Out of Control Dot Rate |
<0.0001 |
Earth Leakage Current |
<2mA |
MTBF |
>5,000 hours |
LED Life Time |
>100,000 hours |
Power Supply |
220V / 50HZ |
Brand |
Chuanglian |
Control Card |
LINSN |
Operation Software |
LEDStudio |
