Indoor P3 Flexible Led Screens Wireless / Bluetooth Control With RoHS

Large Image : Indoor P3 Flexible Led Screens Wireless / Bluetooth Control With RoHS

Product Details:

Place of Origin:	Shenzhen China
Brand Name:	S&B
Certification:	CE, RoHS, CCC
Model Number:	SBI-P3
Warranty time::	36 months

Payment & Shipping Terms:

Minimum Order Quantity:	1 Piece
Packaging Details:	Plywood case; flight case
Delivery Time:	10~20 days
Payment Terms:	T/T
Supply Ability:	5000sq.meter / Month
shape option:	round, convex, concave

Contact Now

Detailed Product Description

Highlight:	flexible led display screen

Indoor P3 Flexible Led Screens Wireless / Bluetooth Control With RoHS

Advantage:

1. High Contrast ratio: 4000:1

2. First-class LED chip

3. Clear vivid image quality

4. Long life time

5. Easy Installation & Operation

6. Convenient Servicing

Characteristics:

1. CE&RoHS certificate

2. 36 months warranty and Life long free tech-support

3. Excellent contrast ratio, high resolution/high definition

4. Perect uniformity and no mosaic

5. Waterproof IP65

6. Light weight and easy to install

7. Available models: P10, P12, P16, P20, P25, P 31.25, ect.

SBI-P3 (Pitch 3mm indoor full color-1/16 scan)

Technique	SMD
Pixel structure	1R1G1B 3in1
Pixel pitch	3mm
Pixel density	111,110 dots/㎡
Luminance	2,200cd/㎡
Module dimension	192mm(W) * 96mm(H)
Module resolution	64 pixel(W) * 32 pixelmm(H)
Cabinet dimension	384 * 576mm
Cabinet resolution	128 * 192
Cabinet area	0.22 sq.meter
Optimal visual distance	>3m
Visual angel	140 degree (H/V)
Max power consumption	≤1500w / ㎡
Average power consumption	≤850w / ㎡
Brightness adjustment	Adjust according to the enviroment
Brightness adjustment	brightness software (0%-100%adjustable)
Gray scale	point by point 4096 gray gradelevels of
Gray scale	each color,16 bits γ correction avilable
Drive mode	1/16 dynamic scan, constant current
Frame frequency	≥60HZ
Refresh frequency	≥1000HZ
Input voltage	AC 90~260 volts
Operation temperature	﹣40℃~ +60℃
Operation humidity	10％～90％
Input signal	S-video, RF, RGB, Yuv, YC, composite…
Control system	DVI card + master control card + receiver card
MTBF	>5000 hrs
Life span (50% brightness)	100,000 hrs
Malfunction dot rate	1/10000
Ingress protection rate	IP31
Cabinet material	Epoxy paint coated, aluminum / iron

Application:

Commercial advertising, Stadium perimeter, mobile media, night club, entertainment events, business establishments, such as banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio, shopping malls, railways, airports, harbors, etc;
