White LG Panel Wall Fixing Commercial LCD Displays , 21.5" Wifi Digital Signage
Quick details:
- Stand alone version, play video, image media player.
- Superthin design, wall mount style.
- High grade LCD Panel, original LG / SAMSUNG / AUO.
- Support CF Card, SD card and USB Port.
- With lockable door to guard against theft.
- Built-in high quality speaker stereo 2pcs *5W..
- OEM and ODM are available.
Specifications:
|
Technical Parameter for
22Inch LCD Panel
|
Panel Size
|
21.5 inch TFT LCD
|
|
Aspect Ratio
|
16:9
|
|
Active Area
|
474.9 mm(H)X 297.1mm(V)
|
|
Visual angle
|
89 / 89/89/89
|
|
Max. Resolution
|
1024x768
|
|
Dot Pitch
|
0.294(H) x 0.294 (W)mm
|
|
Number of Color
|
16.7M
|
|
Brightness
|
350cd/m2
|
|
Contrast Ratio
|
1000:1
|
|
Responsive Time
|
6ms
|
|
Panel Life
|
above 60000 hours
|
|
Touch Panel
|
Touch technology
|
Two point, multi points touch
|
|
Light transmittance
|
100%
|
|
Physical resolution
|
1000x1000
|
|
Touch media
|
Finger/touch pen opaque objects
|
|
Response time
|
≤10ms
|
|
Click life time
|
≥60 M times
|
|
power
|
1W
|
|
Max current
|
<350 MA
|
|
Storage Medium
|
Flash memory card, SD Card
|
2gb to 36gb for the capacity
|
|
Support Ad files
|
Video formats
|
MP4(AVI:DIVX/XVID),MPG2(DVD:VOB/MPG2), MPEG1 (VCD:
DAT/MPG1)
|
|
Audio formats
|
MP3
|
|
Photo formats
|
JPEG/BMP/TIFF/PNG/GIF
|
|
OSD Language
|
English, Chinese, French, German, Italian, Spanish,Arabic
|
|
Audio output
|
stereo L/R, 5W*2, 8Ω
|
|
Power supply
|
AC 110V - 240V, 50/60HZ
|
|
Storage Temperature
|
-7 to 65 Celsius degree
|
|
Normal Working Temperature
|
-5 to 65 Celsius degree
|
| Warranty |
1 year |
| Maximum power consumption |
220W |
|
System info.
|
OS
|
Android
|
|
|
CPU
|
Allwinner A20, Cortex-A7, 1.0GHz ,Dual core
|
|
|
Storage
|
4G (NAND FLASH )
|
|
|
Memory
|
DDR3 1G
|
|
|
Storage Extension
|
Up to 32GB SD/TF Card extension, also supports SATA driver
extension
|
|
|
PC I/O Connectors
|
2 x USB, 2xPS / 2.1 x RJ45, 1x Line-in, 1x Earphone,
1xMicrophone, 1xVGA
|
|
|
Wifi
|
High-performance WIFI 802.11b/g/n
|
|
|
Audio
|
Built-in HD audio 8 audio system
|
|
PC Specification
|
CPU
|
Intel G2020/2.9GHZ/ Dual core
|
|
|
RAM
|
DDR3.2GB
|
|
|
HDD
|
S-Atall 500GB/16MB/5400rpm
|
|
|
Graphics
|
Inter NM10Express
|
|
|
Chipset
|
INTEL 5400
|
|
|
Ports
|
5xUSB, 1xVGA, 1XLAN, 1XAUDIO-OUT, 1XMIC-IN, DVI, HDMI
|
|
|
Power consumption
|
30W
|
|
|
Operating system
|
Windows 8 / 7
|
|
|
Speaker
|
2*10W
|
Description:
1. Main outer shell is made by extra quality Iron material, side frame adopts Aluminium Alloy Mould,
front frame adopts 4-6mm thickness Tempered glass, which can protect the LCD panel
2. Optional panel size: 15.6”, 17”, 19”, 22”, 24”, 26”, 32”, 39”, 42”, 47”, 55”, 65”, 70”.
3. Different color optional, normally using silvery, white, black.
4. White and black color, stylish design, freestanding IPAD style, dust-proof and waterproof, the overall nice.
5. Imported brand full HD LCD panel, clear and bright picture quality, more lower power consumption.
6. With lockable door to avoid take away flash memory card and advertising playing program.
7. Built-in IR touch screen, using the latest high precision touch technology, unique circuit design, intelligent
decision and infrared anti-interference and other advanced technology, strong stability, sensitive response.
8. Vertical solid base, it is easy to operate and install.
9. Support 3G, WIFI, Ethernet network, optional.
10. Support 5 groups of auto power on / off timer, be able to set those 5 groups of time one day and
7 days in one week.
11. The products pass the national mandatory 3 c authentication, and has the national high and new
technology enterprise development of the software copyright certificate.
12. You can set rolling caption and LOGO on the display, rolling caption is showed at the bottom of
LCD Screen in the advertisement program.
13. With super-long time setting function, Automatic to play advertising programs , all the year round without the
personnel control .
14. Upgrade contents of the memory card (or built - in memory) by simple inserting an USB flash drive, no need to
take out to the memory card.
Application:
1. Business Organizations: supermarket, large-scale shopping malls, exclusive agency, chain shops,
large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy.
2. Financial Organizations: Banks, negotiable securities, funds, insurance companies, pawnshops;
3. Non-profit Organizations: Telecommunications, post offices, hospital, schools;
4. Public Places: subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls,
5. stadiums, museums, convention centers, ticket agencies, HR market, lottery centers;
6. Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms, property brokers;
7. Entertainments: Movie theaters, fitness halls
Our competitive advantage:
1. Provide with OEM＆ODM Service, We have engineers, professional team for your OEM/ODM service
requirements.
2. Low MOQ. Our MOQ is 1 pc for different sizes and types.
3. Saving your dollars, we will help you to find the cheapest and also safest shipping way and shipping
