University Touch Screen Interactive Digital Signage WIFI / 3G/ RJ45 Network

Large Image : University Touch Screen Interactive Digital Signage WIFI / 3G/ RJ45 Network

Product Details:

Place of Origin:	China
Brand Name:	Tmtouch
Certification:	CE, FCC, Class B, RoHS
Model Number:	24W66

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	Negotiate
Packaging Details:	PE protective film+PE foam+honeycomb box+wooden case
Delivery Time:	25day
Payment Terms:	L/C, T/T, Western Union, MoneyGram, D/P,
Supply Ability:	3, 000set per month

Contact Now

Detailed Product Description

Screen Size:	24inch Samsung A-grade LCD Panel	Available Size:	21.5" 22" 23.6" 32" 27" 42" 55"
Resolution:	1920*1200	Viewable Area:	518.4×324.0 Mm
Brightness:	250 Cd/m2 (Typ.)	Contrast Ratio:	1000 : 1 (Typ.)
Support Color:	16.7M (6-bit)	Viewing Angle:	89/89/89/89 (Typ.)(CR≥10)
Highlight:	digital media signage

University Touch Screen Interactive Digital Signage WIFI / 3G/ RJ45 Network

Features

1.Managing and monitoring players remotely
2.No failure caused by network disconnection
3.Update advertising content through internet and store in local
4.Support multicast / on-demand / RLSP / MMS real time streaming wave
5.Support online stream media, such as web TV and web film
6.With freely split-screen function, show different content
7.Support real-time clock, auto power on/off

8.Support video/image/scrolling subtitles/weather and date/Logo

9.Support images and text mixed, maximum superimposed to 5 layers

10.32bit true color OSD could appear in any position

Parameters

Touch Screen	Touch Technology	Dual-point IR touch screen with 6mm tempered glass
	Scanning Speed	>50 Scans/S
	Resolution of touch screen	32767*32767
	Touch Precision	0.625mm
	Touch Intensity	Over 60,000,000 Touch
	Response Speed	8-12ms
	Minimum Touch object	>=5mm
	Transparency	95% to 100%
Computer	Main Board／CPU	Intet A201.2Ghz, Cortex-A8
	RAM	DDR2 512MB
	Hard Disk	4GB SSD
	Video Format	MP4,AVI,DIVX,XVID,DVD, VOB,DAT,MPG,RM,RMVB,MKB,MOV, HDMOV,M4V,PMP,AVC,FLV
	Picture Format	JPG, JPEG,PNG,BMP,GIF
	Audio Format	MP3/WMA/OGG/AAC/AC/DTS/FLAC/APE
	Input Voltage	100-240VAC 50/60Hz
	Power Output	DC 12V, 24V, 3-5A
	Network	LAN/WIFI/3G
	Operating System	Android
Others	Temperature Range	Operating: 0°C to 40°C, Storage: -20°C to +60°C
	Humidity Range	operating: +20℃ to +80℃,storage:+10% to +90%
	Cabin material	Steel enclosure
	Cabin Treatment	Baking varnish, anti-magnetic and anti-static treatment
	Interface	1/HDMI,1/VGA,1/DVI,2/USB, ,1/LAN, 1/SD,1/SIM, Audio Input
