Indoor P18 LED Curtain Display Stage Background 1R1G1B LED Screen

Large Image : Indoor P18 LED Curtain Display Stage Background 1R1G1B LED Screen

Product Details:

Place of Origin:	Shenzhen China
Brand Name:	SKYVIEW
Certification:	3C/GMC/ISO9001/CCPC
Model Number:	P18.0mm

Payment & Shipping Terms:

Minimum Order Quantity:	1sqm
Price:	1-100000usd
Packaging Details:	Wooden Case/ Flight Case
Delivery Time:	7-15 Working Days
Payment Terms:	L/C, T/T
Supply Ability:	>500sqm/month

Contact Now

Detailed Product Description

Product Name:	Indoor Background High Brightness P18.0mm LED Led Curtain Display Screen	Pixel Pitch:	18mm
Size Of Panel:	480 X160	Brightness:	6000
Usage:	Advertising	Pixel Density:	6944
Weight:	46 KG For Each Cabinet
High Light:	Led Curtain Wall , Outdoor Led Curtain

Indoor P18 LED Curtain Display Stage Background 1R1G1B LED Screen

Description

Panel input format(with video processor), such as ,VGA,DVI,RGBHV, PbPr (HDTV),Composite, S-Video, TV . There are also interfaces for Sound signal and video signal. The gray level si 65536 level, and the brightness, contrast,saturation, chroma can be adjusted by manual and sensor. Show all sort of word, text, graph, picture, video, 2-dimention, 3-dimention cartoon and other information with your PC does synchronously or asynchronously. Can be used outdoor in all kinds of circumstance, and excellent capability of antisepsis, waterproof. More faster to assemble or disassemble it without any tool.

1. The P18 LED

curtain display features light weight and very thin body design. The cabinet weight is only 5.2kg.
2. The anti-reflective masking ensures clearer and more beautiful images.
3. As the display screen is flexible, the maintenance and installation is very convenient.
4. The steel materials with high thickness provide the cabinets with high structural stability. The cabinets won't be deformed even after repeated installation.
5. According to clients' demands, we can offer curtain LED displays with IP67 protection grade for both front and back sides.
6. Constructed using superior quality materials, the product can be utilized in areas with different temperature conditions. In addition to standard products, we can also offer products supporting working temperature from -30℃ to 60℃.
7. We provide our products with 2-year warranty and lifetime maintenance, and we can also offer 24/7 service.

Technical Specifications

Cabinet size	600mm*600mm
Density of pixel	2844 dots/sqm
Pixel composition	1Red, 1Green, 1Blue
Supply voltage	AC 220V/50HZ or AC110V/60HZ
Average power consumption	300 w/sqm
Pixel pitch	18.75mm
Luminance of white balance	≥5800 cd/sqm
View angle(H/V)	110°/90°
Gray scale	display≥16.7 M color(synchronized)
Driving method	Static constant driving
Refresh frequency	>400 Hz/s
Frame frequency	>60 Hz/s
View distance	>18m
Operating temperature	-20~60 °C
Mean Time between failures	>100, 000 hours
Working life	> 1, 000, 000 hours
Malfunction dot rate	<0.0001
Display content	Text, Graphics, Logo, Animation, live video, etc.
Communication distance	<100m (>100m optical fiber)
Cabinet structure	Steel
Control system	LINSN
Connection method	Synchronized Computer(windows XP, vista), TV, DVD player, VCD player, VCR, etc.
LED Encapsulation	SMD 5050 (3 in 1)
Waterproof Grade	IP65

Applications

The RGB LED Display Are Very Popular In Outdoor Field. This Type Screen
Are Popular Used Outdoor Shopping Center ,Outdoor Building,Foodball Field,crossroad,
highway,Concert,airport etc;

competitive advantage

1. Good Sevice , 24/7 online support service.
2. Good Quality For Every LED Display Product.
3. Good Price.
4. High Quality Driving IC .
5. Red,Green And Blue LED Chips Incorporated Encapsulation ,Better Perspective.
6. Two Years Maintenance Service With Free.
