22 32 55 Inch Wall Mounting Indoor LCD Digital Signage Display with wifi / 3G / Android

22 32 55 Inch Wall Mounting Indoor LCD Digital Signage Display with wifi / 3G / Android

22 32 55 Inch Wall Mounting Indoor LCD Digital Signage Display with wifi / 3G / Android
22 32 55 Inch Wall Mounting Indoor LCD Digital Signage Display with wifi / 3G / Android 22 32 55 Inch Wall Mounting Indoor LCD Digital Signage Display with wifi / 3G / Android

Large Image :  22 32 55 Inch Wall Mounting Indoor LCD Digital Signage Display with wifi / 3G / Android

Product Details:
Place of Origin: Shenzhen ,China
Brand Name: LanGao
Certification: CE/ROHS/FCC/UL/ISO/3C
Model Number: LGLCD5
Payment & Shipping Terms:
Minimum Order Quantity: 1sqm. / 1 piece
Packaging Details: Plywood or Flight Case
Delivery Time: 10-20 days
Payment Terms: T/T ,L/C ,Paypal or
Detailed Product Description
Application: Indoor Brightness: 400cd/m2 ,500cd/m2 To 550cd/m2
Signal Port: USB / SD / HDMI / VGA / AV Input Voltage: AC100 To 240V 50 /60 HZ
Panel Size: 42 Inch LCD Panel: LG /Samsung Panel
Certification: CE, Rohs, ISO9000, BV ,FCC Resolution: 1920*1080
High Light:

vertical digital signage display

,

digital signage screen





22 32 42 55inch Wall Mounting LCD Indoor Digital Signage Display with wifi / 3G / Android


Products Features

1. Our shell is made by high-class metal material,black or silver color etc, back-fixing mode with nice appearance. Outer shell color can be customized.
2. With a protection layer of acryl, perfectly clear tempered glass on the surface of the LCD screen to protect the screen being damaged.
3. Choosing Samsung, LG, Chi Mei, AU, Toshiba, SVA etc 55" Brand LED panels. A Class 335 standard, full new and factory original packing screen.
4.Theft-protection device effectively prevent the player and CF card from being stolen in public place.
5. Password can be set to protect the contents.
6. Password can be set to lock the keyboard of the remote controll.
7. Support software updating, new function can be customized according to customer’s needs.
8. Built-in two high quality stereo speakers, rated power is 2 x 1.5W.





Specifications

Panel size

42" LCD

Display area(mm)/mode

930(W)×523(H)  16:9

Maximum resolution

1920*1080

Display color

16.7M

Pixel Pitch(mm)

0.4845(H)×0.4845(V)

Brightness (nits)

600cd/m2

Contrast

1000:01

Visual angle

178°/178°

Response time

5ms

Life(hrs)

>60,000(hrs)

Input and output

RJ45

Included(Network version only)

3G or WIFI Module

Included(Network version only)

USB

1 ( USB2.0 interface)

SD

1 (Compatible MMC/MS)

CF

1(optional)

L/R audio input

1 (RCA*2)

L/R audio output

1 (RCA*2)

Speaker

2×5W(9Ω)

Video

Color system

PAL/NTSC/SECAM

Remote controller

IR Remote Controller

OSD display( screen menu display)

Menu language

Chinese/English( Multiple Language Supported)

Power

Power supply

AC100~240V 50 /60 HZ

Maximum power consumption

<=220W

Standby power consumption

<5W

Temperature

Working temperature

0°C~50°C

Storage temperature

-20°C~60°C

Working humidity

85%

Storage humidity

85%

Appearance

Color/appearance

White,black,customized

Case

Metal case SPCC

Installation

Wall mount,rack mount optional

Specs

970mm×563mm×59mm

After packing size

1100mm×680mm×120mm

Gross Weight

35kg

Quality Standard

ISO9001,CCC

Detailed functions

Video format

MPEG1/MPEG2/MPEG4/DivX/ASP/WMV/AVI

Audio format

Wave/MP3/WMA/AAC

Image format

JPEG/BMP/TIFF/PNG/GIF

Image resolution

480P/720P/1080P


 Play mode: Power on, single card auto loop play;classified files auto loop play; multi cards auto loop display etc.
 Time: year/month/day/week/h/m/s, in the top right corner (open and close optional) .
 Timing open & close: Per day 5 times, 7 days a week, free time.
 Timing play: 7 days a week, free set the play program everyday.
 Alarm clock: Set 5 alarms one day, once ring the alarm, play the specified program .
 OTG: Support copy, delete, remove, rename, build new file among different cards.
 Running subtitle: Can set the play location, word size, color and back-color.
 Log files: Record the play time (concise to second), the play contents.
 Angle subscript display function: Can set the play time, just support BMP picture with  bigges t resolution 160*90.
 Memory function: Power off, memory the time of the play; power on, play from the time, not  from beginning .
 Key and lock function: Use the remote controller before input the keyword.
 Encrypt CF card: Play the contents in the CF card before input the keyword .
 Sound volume: Can set the volume of sound in the different time.
 Upgrade software: Just put the upgrade file in the storage cards.
