concert led screen

Technical Specification:

PH5mm 1R1G1B full-color indoor indoor rental Led Display

Pixel Configuration

1R,1G,1B

Physical/Real pixel pitch(mm)

5

Pixel density(dots/sqm)(physical/real)

40000

Calibrated Brightness

8000 nits(adjustable)

Color temperature

3,500° — 9,500° K(adjustable)

Contrast ratio

4,000:1

Brightness Adjustment

100 grade auto-adjustment

View angle(degree)(50% brightness)

Horizontal: 120° (60° off center); Vertical: 70° (+25°/-45° off center)

Color Capability

4.4 trillion

Interface port

DVI interface(DVI connector)

 Input signal

Video: PAL/NTSC Optioned: VGA, video, DVD,TV

Protection grade

IP65 front side/IP54 backside

Operating temperature(Celsius degree)

-20~+55'

Storage temperature(Celsius degree)

-30~+55'

Operation Humidity(RH)

0-95%

Storage Humidity(RH)

0-99%

Lifetime(hours)(50% brightness)

100,000 hours

Servicing

Front and Back

Power supply

100-240V/50-60HZ

LED Drive

1/8 Constant driving

Power consumption(W/sqm):Maximum

1800

Power consumption(W/sqm):Average

630-810

Module Configuration(Pixels quantities of the module)

length

32

height

 32

Module Dimensions(mm)

length

160

height

160

Cabinet Configuration(standard)(module quantities of the cabinet)

length

4

height

6

Cabinet Dimensions(standard)(mm)

length

960

height

960
