110 To 220VDC Rental LED Display Offer Guidance On Installation And System Operation
Pixel pitch:10mm,12mm,12.5mm,14mm,16mm,20mm,25mm,31.25mm,37.5mm...
Application :billboard,concerts and and stage, events,stadium,advertising ,train station,shopping center,meeting screen ,airport ,mall...
Features:
1, LED rental screen cabinet ultra-light, ultra-thin , simple structure, high compatibility , fast and quick installation, removal, saving time and labor costs.
2, LED rental screen cabinets , easy and convenient to install, low cost of installation; low -Consumption cabinet , save operating costs and reduce labor costs.
3, LED rental screen cabinet is designed with Die-cast aluminum , which is high strength , high toughness , high precision, easily deformed and highly wind resistance
4, High compatibility , the new structure designed to meet the lifting, stacking requirements to meet indoor and outdoor LED display requirements.
5, One cabinet can be installed in a few seconds with high precision, large area arbitrarily assembled .
6, No Screen noise , low power consumption, heat dissipation , high stability
7, According to customer requirements and site environment, tailored to the most suitable LED display rental solutions.
Specifications:
| Usage |
Outdoor |
| Pitch(mm) |
12 |
| Pixel Constitute |
1R1G1B |
| Pixel Density(dots/sqm) |
6944 |
| LED--Opto+Silan |
R:λd(625-630nm) G:λd(522.5-525nm) B:λd(467.5-470nm) R:(450-500mcd) G:(1600-1800mcd) G:(350-400mcd)
|
| Module Size(mm) |
192*192 |
| Module Resolution |
16*16 |
| Recommended Minimum Viewing Distance/M |
12 |
| Viewing Angle(°C) |
V40, H110 |
| Average Power Consumption |
300W/sqm |
| Brightness (white balance) |
≥7000cd/sqm |
| Size of cabinet(mm) |
768*576*150 |
| Weight of cabinet |
60kg/㎡ |
| Cabinet pixels(dot) |
64*48 |
| Frame frequency |
≥60Hz |
| Refresh rate |
≥2000Hz |
| Grey color |
≥16.7M |
| Brightness adjustment |
256 grade manual, 8 grade automatic |
| Average NO failure time |
5000 hours |
| Life span |
100000 hours |
| Working temperature |
-30 °C ～+60°C |
| Driving Voltage |
5VDC |
| Working Voltage |
110 to 220VDC |
| Scan Mode |
1/4 |
| Display Function |
Video, Animation, Graphics, other |
| Operating system |
Windows (2000/XP/Vista) |
| Control distance |
CAT5 cable:<100 m; Single fiber:<10 km |
