2000 Hz P10 Rental LED Display For Events / Stadium / Advertising
Application :billboard,concerts and and stage, events,stadium,advertising ,train station,shopping center,meeting screen ,airport ,mall...
Feature:
1, LED rental screen cabinet ultra-light, ultra-thin , simple structure, high compatibility , fast and quick installation, removal, saving time and labor costs.
2, LED rental screen cabinets , easy and convenient to install, low cost of installation; low -Consumption cabinet , save operating costs and reduce labor costs.
3, LED rental screen cabinet is designed with Die-cast aluminum , which is high strength , high toughness , high precision, easily deformed and highly wind resistance
4, High compatibility , the new structure designed to meet the lifting, stacking requirements to meet indoor and outdoor LED display requirements.
5, One cabinet can be installed in a few seconds with high precision, large area arbitrarily assembled .
6, No Screen noise , low power consumption, heat dissipation , high stability
7, According to customer requirements and site environment, tailored to the most suitable LED display rental solutions.
Specification:
| Usage |
Indoor |
| Pitch(mm) |
10 |
| Pixel Constitute |
1R1G1B |
| LED Chips--Opto+Silan |
R:λd(625-630nm) G:λd(522.5-525nm) B:λd(467.5-470nm) R:(180-200mcd) G:(330-360mcd) B:(95-105mcd) |
| Pixel Density(dots/sqm) |
10000 |
| Module Size(mm) |
160*160 |
| Modules for 1 sqm(pcs) |
19.5 |
| Recommended Minimum Viewing Distance(m) |
≥10 |
| Viewing Angle(°) |
V60, H120 |
| Average Power Consumption |
105W/sqm |
| Brightness (white balance) |
≥1500cd/sqm |
| Refresh rate |
2000Hz |
| Average NO failure time |
5000 hours |
| Life span |
100000 hours |
| Working temperature |
-20 °C~+65°C |
| Driving Voltage |
5VDC |
| Working Voltage |
110 to 220VDC |
| Driving mode |
1/8 |
| Display Function |
Video, Animation, Graphics, other |
| Operating system |
Windows (2000/XP/Vista) |
| Control distance |
CAT5 cable:<100 m; Single fiber:<10 km |
Remarks:
1.Guarantee: 2 years(means free replace or maintain parts) since finished installation.
2. Technical support:We will provide you free technical support through email, fax and phone call. Every time when there is some problem for the LED display, if your engineer can not solve it, Please contact with us asap and send us pictures and descriptions. Then we will try to solve it for you asap.
