China Signage Display Online Marketplace
High quality, Best service,Reasonable price. |
|
Product Details:
Payment & Shipping Terms:
|
| Screen Size: | 40inch A-grade LCD Panel | Available Size: | 22" 32" 42" 55" |
|---|---|---|---|
| Resolution: | 1920*1080 | Viewable Area: | 885.6×498.15 Mm |
| Brightness: | 450 Cd/m2 (Typ.), Up To 3000 Cd/m2 | Contrast Ratio: | 5000 : 1 (Typ.) |
| Support Color: | 16.7M (8-bit) | Viewing Angle: | 89/89/89/89 (Typ.)(CR≥10) |
| High Light: | digital media signage,digital advertising board |
||
Lobby / Concert Interactive Digital Signage IR Touch Screen Display
Features
1.Managing and monitoring players remotely
2.No failure caused by network disconnection
3.Update advertising content through internet and store in local
4.Support real-time clock, auto power on/off
5.Support multicast / on-demand / RLSP / MMS real time streaming wave
6.Support online stream media, such as web TV and web film
7.With freely split-screen function, show different content
8.Support images and text mixed, maximum superimposed to 5 layers
9.Support video/image/scrolling subtitles/weather and date/Logo
10.32bit true color OSD could appear in any position
Parameters
| Touch Screen | Touch Technology | Dual-point IR touch screen with 6mm tempered glass |
| Scanning Speed | >50 Scans/S | |
| Resolution of touch screen | 32767*32767 | |
| Touch Precision | 0.625mm | |
| Touch Intensity | Over 60,000,000 Touch | |
| Response Speed | 8-12ms | |
| Minimum Touch object | >=5mm | |
| Transparency | 95% to 100% | |
| Computer | Main Board／CPU | Intel i5 |
| RAM | 4G DDR3-1333 | |
| Hard Disk | Samsung/Western Digit SATAII 7200RPM/500G | |
| Video Format |
MP4,AVI,DIVX,XVID,DVD, VOB,DAT,MPG,RM,RMVB,MKB,MOV, HDMOV,M4V,PMP,AVC,FLV |
|
| Picture Format | JPG, JPEG,PNG,BMP,GIF | |
| Audio Format | MP3/WMA/OGG/AAC/AC/DTS/FLAC/APE | |
| Input Voltage | 100-240VAC 50/60Hz | |
| Power Output | DC 12V, 24V, 3-5A | |
| Network | LAN/WIFI/3G | |
| Operating System | Windows XP/7 | |
| Temperature Range | Operating: 0°C to 40°C, Storage: -20°C to +60°C | |
| Others | Humidity Range | operating: +20℃ to +80℃,storage:+10% to +90% |
| Cabin material | Steel enclosure | |
| Cabin Treatment | Baking varnish, anti-magnetic and anti-static | |
| Interface | 1/HDMI,1/VGA ,1/DVI,4/USB,1/LAN, Audio Input |
