P4.8 HD Indoor Full Color LED Rental Display Billboard Die Casting Aluminum Cabinets
1. Easy to install and transport
The indoor rental led display are light weight, easy to install and disassemble, etc.. It will cut down the cost for transportation and installation.
2. The stylish appearance
The indoor rental led display uses international stylish super-thin case, are lighter and thinner than normal cabinet, with anti-water, anti-damp, anti-corrosion reaching IP65 grade at customers option.
3. Good after-sales service
Our after-sales engineers have been in LED field for more than 7 years who is sophisticated in programming all kinds of control systems, extending professional maintenance or repairing skills to customers.
4. Good quality and competitive price
LanGao is a professional manufacturer engaged in LED display more than 7 years. We do the LED encapsulation by ourselves (Quality is under strict control, prices are very competitive).
5. Pixel-To-Pixel Calibration System
It is developed to solve the problem of nonuniformity of LED displays. First, the system uses a digital camera to get pictures of displays; then, it analyzes the pixel brightness from the pictures and calculates the coefficients for calibration; finally, it sends the calibration coefficients into the LED display control system and fulfills calibration.
Parameters:
|
Pixel pitch
|
4.8mm
|
|
Cabinet Resolution
|
104 pixel(W)*104 pixel (H)
|
|
Pixel configuration
|
1R1G1B(3 in 1)
|
|
LED Type
|
SMD3528
|
|
Pixel Physics density
|
43403dot/m2
|
|
Driving mode
|
1/13 Scan constant current
|
|
Refresh rate
|
≥ 2000Hz (Support high refresh rate due to the system layout)
|
|
Driving IC
|
SUM2016
|
|
Grey Level
|
≥ 14BIT (Due to the system and IC layout)
|
|
Cabinet size
|
500mm*500mm
|
|
Brightness
|
1000cd/ m2
|
|
Color temperature
|
8000K±500 (can be customized)
|
|
Viewing angle
|
H:140° V:120°
|
|
Best view distance
|
≥ 4m
|
|
Working voltage
|
AC 220/110V/50Hz ± 10%
|
|
Module working voltage
|
DC 4.2V-5V
|
|
Max power consumption
|
480W/pcs
|
|
Average consumption
|
240W/pcs (under normal situation)
|
|
Life span
|
100000 hours
|
|
Working temperature
|
-30℃ ~ 50℃
|
|
Net weight
|
10Kg/pcs
|
Advantage :
1. CNC + Die Casting process cabinets
The flatness of led panel surface is greatly improved by its CNC+Die Casting molding process (precision up to 0.05mm), thus it ensures the full screen’s seamless and precise installation.
2. Super Slim
The thickness is 60mm. This saves your installation space and packing size, it ensures the greatly fast movement and installation.
3. Light Weight
The weight of full panel is only 10KG, can be easily hanging up by one person, with only two person can finish 12sqm led screen installation in 30minutes, it saves your time and labor cost.
4. Convenient and Fast Installation
We adapted Plug and play designing for this series, the power and signal connector is quite easy and fast for in&out operation; and the signal connection can be in horizontal and vertical ways, it satisfied the rental application in any cases.
