Product Details:
Payment & Shipping Terms:
|
| High Light: | mobile barcode scanner,long distance barcode scanner |
||
|---|---|---|---|
1. Windows mobile 6 OS
2.WIFI WPS Bluetooth
3.GPRS/EDGE
4. 3.2inch TFT LCD display (320x240) 65k color
5.Honeywell 2D reader/RFID
Specification:
| Hardware | ||
| Core board | ||
| WM6.1/6.5 OS | option1(Module) | Marvell PXA310(624MHz)+qualcomm (GSM Quad-band 850/900/1800/1900MHz, GPRS, EDGE/WCDMA 850/1900/2100MHz HSDPA 3.6Mbps) |
| WM6.1/6.5 OS | option2(Module) | Marvell PXA310(624MHz)+qualcomm EVDO (800MHz, CDMA 1X, EVDO) |
| WM6.1/6.5/CE OS | option3(Module) | Marvell PXA300(No communication module.) |
| Memory | Flash ROM | 256MB |
| RAM | 256MB DDR | |
| Extend Slot | Micro SD 16G (SDHC) | |
| Motherboard | ||
| Display | 3.2inch TFT LCD display (320 x 240) 65k color/touch panel/Transflective screen | |
| Form Factor | Bar type classical Pocket PC,Industrial appearance | |
| GPS Solution | Ublox The 5th Generation | |
| Wire Transmission | USB 2.0 Full Speed, charging/sync | |
| Bluetooth | Bluetooth SIG version 2.0 compliant; Supported profiles: headset, hands-free, object push, serial port, dial-up network | |
| WiFi | WiFi (802.11 b/g) | |
| RFID | read and write (13.56MHz ISO 14443A/B) | |
| Laser scanner | Honeywell 2D reader/Can be replaced by symbol 1D reader head/ Can be replaced by NEWLAND:EM1300 | |
| C-MOS imager | ||
| External Interface | RS232;SPI;print | |
| Protection class | IP54 | |
| Drop resistance level | 1.8m | |
| Audio | Handfree | Yes |
| StereoBlueTooth earphone | Yes | |
| Ringtone | support 64-chord MIDI, MP3, WMA, WAV | |
| Playback | support MIDI, MP3, WMA, WAV, AMR | |
| Speaker | support handfree | |
| Network Led | red/green/yellow | |
| Keypad | Front | Number key, Function key |
| Side | Volume up, Volume down,camera | |
| Interface | Mini-USB connector | USB2.0 connection and power charging |
| SIM card slot | Yes | |
| Audio Jack | NO | |
| Battery | Type | rechargeable Li-ion battery 3000mAh |
| Standby Time | 500hours | |
| Calls Time | Up to 6hours | |
| Charging Time | 4 hours | |
| Physical Characteristics | Dimension | 149*72*28mm |
| Weight | 275g | |
| Key Software | ||
| Operating System | Windows Mobile 6.1/6.5 professional | |
| KVM | JAVA MIDP 2.0 | |
| Default language | English | |
| Package Contents | ||
| Standard Packaging: Main Unit*1pc, Charger*1pc, USB Cable*1pc, battery*1pc | ||
