Real Pixel Flexible LED Screen P10 , 10000/㎡ Pixel Density For Super Market

Real Pixel Flexible LED Screen P10 , 10000/㎡ Pixel Density For Super Market

Real Pixel Flexible LED Screen P10 , 10000/㎡ Pixel Density For Super Market
Real Pixel Flexible LED Screen P10 , 10000/㎡ Pixel Density For Super Market

Large Image :  Real Pixel Flexible LED Screen P10 , 10000/㎡ Pixel Density For Super Market

Product Details:
Place of Origin: Shenzhen, China
Brand Name: D-King
Certification: CE RoHS
Model Number: D-KingP10
Payment & Shipping Terms:
Minimum Order Quantity: 1 Square Meters
Price: Negotiate
Packaging Details: wooden box or flight case
Delivery Time: 10-25 working days after receipt your deposit
Payment Terms: 30% by T/T as deposit, balance by T/T before delivery
Supply Ability: 4000 square Meters Per Month
Detailed Product Description
Features: Seamless, Waterproof Module Size: 320*160mm
Pixel Density: 10000/㎡ Pixel Pitch: 10mm
Product Name: Flexible LED Panels View Angle: 120°/120°
High Light:

led advertising displays

,

led video display

Real Pixel Flexible LED Screen P10 , 10000/㎡ Pixel Density For Super Market
Product Description:
Application
LED flexible screen is one of the most flexible and lightweight LED video screens on the market. They are
easy to operate and they can be set up in a matter of minutes. We offer high resolution LED video screens
to display videos with detail. Our panels easily attach together with our quick lock system to make as larger
screen as you may want. They are flexible in all directions to allow you to bend and shape around structures
for a more creative effect. They are 60 to 90% lighter weight than most other LED video screens. You can
use any computer with a DVI-D connection to send a video or image source to the screen via a single
sending unit. Each panel has a card input and output for signal connections. For transportation the panels
simply fold into themselves and are stored in a road case. Flex LED systems have been used on major
concert tours and television events. Flexible LED panels are perfect for trade shows, arenas, theaters,
universities, concerts, events and more.
Technical Parameters:
The main parameter

P10 Integrated 3in1 SMD Series

Physical Pixel Pitch

10mm

Module Size

320*160mm

Pixel Density

10000/㎡

Pixel Configuration

1R1G1B SMD3528

Best Viewing Distance

10m

View Angle(Horizontal)

120°/120°

Brightness

≥1000cd/㎡

Driving Method

1/8 Constant Driving

Control Mode

Real Pixel

Cabinet Size

1280*960mm

Cabinet Resolution

128*96

Cabinet Weight

50kg

Maximum Power Consumption

600W/㎡

Operating Voltage

220±10% or 110±10%

Feature
1. Flexible--It is capable of being flexible, convex, concave even twisted for to be used for any indoor
conventional applications.
2. Integration System--Separate power supply system and data transmission system to make screen low heat and image quality.
3. Easy Installation --Full backup magnets system to attach on any mental sheet.
4. Long-distance power supply--Small Cable, clean back side, and save space.
5. With a very high refresh rate, the images in the screen are much more true to nature and there is no lose

of visualization when using camera for broadcasting.
6. Super Thin--It is 14mm depth, very slim body.
7. Lightweight--0.38kg/0.84lbs per tile to save labor and transportation cost. Unique design out of box.
8. Plugging system--Safety plugging system

Note: Our company products are constantly upgrading, the above parameters is for reference only, please
refer to the actual parameters prevail
Real Pixel Flexible LED Screen P10 , 10000/㎡ Pixel Density For Super Market 0
