Outdoor flexible led screens wall for shopping square advertising

Large Image : Outdoor flexible led screens wall for shopping square advertising

Product Details:

Place of Origin:	Shenzhen China
Brand Name:	S&B
Certification:	CE, RoHS, CCC
Model Number:	SBO-P12
warranty:	36 months

Payment & Shipping Terms:

Minimum Order Quantity:	1 Piece/Pieces
Price:	Netogiable
Packaging Details:	Plywood with inner carton ; flight case
Delivery Time:	10~20 days
Payment Terms:	T/T
Supply Ability:	5000sq.meter / Month

Contact Now

Detailed Product Description

High Light:

flexible led display screen

flexible led curtain

Outdoor flexible led screens wall for shopping square advertising

2011 Asian cup LED supplier

1. Life long free tech-support

2. CE RoHS certificate

3. 36 months warranty.

4. Competitive price

5. Wide visual angle, smooth surface

6.Excellent contrast ratio, high resolution/high definition

7. High brightness

8.Perect uniformity

9.Waterproof IP65

10. Easy to install

11.Light weight

12. Available Models:PH4, PH5, PH6 PH7.62, PH8, PH10mm, 12mm, 16mm, 18mm, 20mm, 25mm, 31.25mm, ect.

Application:

Our products have been widely used in venues as banks, stock exchange centers, schools, telecommunications, customs, stadiums, studio, shopping malls, railways, airports, harbors, city squares, courts, schools, restaurants etc;

Advantage:

1. High Contrast ratio: 4000:1

2. First-class LED chip

3. Clear vivid image quality

4. Long life time

5. Easy Installation & Operation

6. Convenient Servicing

SBO-P12 (Pitch 12mm outdoor full color-1/2 scan)
Colour temperature	5000~9000 k
Pixel structure	φ3 oval lamp, 2R1G1B
Pixel pitch	12mm
Pixel density	6, 944 dots/㎡
Luminance	7, 000cd/㎡
Module dimension	192mm(W) * 192mm(H)
Module resolution	16 pixel(W) * 16 pixel mm(H)
Cabinet dimension	1152 * 768mm
Cabinet resolution	96 * 64
Cabinet area	0.885 sq. meter
Optimal visual distance	>12m
Visual angel	110 / 50 degree (H/V)
Max power consumption	≤1100w / ㎡
Average power consumption	≤700w / ㎡
Brightness adjustment	Adjust according to the environment
Brightness adjustment	brightness software (0%-100%adjustable)
Gray scale	point by point 4096 gray grade levels of
Gray scale	each color, 16 bits γ correction available
Drive mode	1/2 dynamic scan, constant current
Frame frequency	≥60HZ
Refresh frequency	≥1000HZ
Input voltage	AC 90~260 volts
Operation temperature	﹣40℃~ +65℃
Operation humidity	10％～90％
Input signal	S-video, RF, RGB, Yuv, YC, composite…
Control system	DVI card + master control card + receiver card
MTBF	>5000 hrs
Life span (50% brightness)	100, 000 hrs
Malfunction dot rate	1/10000
Ingress protection rate (Front/ rear)	IP65 / IP54
Cabinet material	Epoxy paint coated, aluminum / iron
Application:	Rental / Permanent installation available
