IP 65 Advertising Electronic Outdoor Led Display Screen Walls Flexible

Large Image : IP 65 Advertising Electronic Outdoor Led Display Screen Walls Flexible

Product Details:

Place of Origin:	Shenzhen, China
Brand Name:	Meltonled
Certification:	CE, RoHS, ISO,FCC,UL
Model Number:	P10

Payment & Shipping Terms:

Minimum Order Quantity:	1pc/1sqm
Price:	1-100000usd
Packaging Details:	Anti-shaking wooden case/flight case/carton
Delivery Time:	8-25 days
Payment Terms:	35% T/T as prepayment,65% T/T as balance at factory
Supply Ability:	>500sqm/month
Delivery term:	Ex-work/FOB/CIF/DDU

Contact Now

Detailed Product Description

High Light:

curved led screen

video display boards

IP 65 Advertising Electronic Outdoor Led Display Screen Walls Flexible

Description:

we are advertising LED display screen manufacturer and global wholesaler of large outdoor and indoor

full color electronic LED matrix display screens, LED signs and LED screens used for mayor advertising

campaigns; placed next to highways, or LED message and video displays for football stadiums,

electronic arrival and departure airport displays signs, LED screen displays for schools or shops and

malls to highlight products and services.

· Our LED display signs have the ISO9001:2000 Quality System Certification;

· CE Certification of our led display signs;

· Rohs Certificates;

· Excellent, Technical Innovation;

· Price performance ratio;

· Contract Performance and Credibility;

· LED Displays with high brightness LED´s;

· Modular LED display screens;

· Our LED Display Screens have two years warranty ;

· Post sale assistance (after sale);

· High expertise and know-how about LED display products;

Personalized sale and less than 24 hours response on all inquiries.

Applications:

advertising media, sports stadiums, airport station integrated information dissemination, business

establishments, public area.

Specifications:

Product model number	Mled-PH10-1
1.Pixel
Pixel L ED	546
Pixel Configuration	1 R, 1G , 1B
Wave length ( nm )	R: 626-628 , G: 518-520 , B: 466-468
Pixels Pitch ( mm )	10
2 . Module
Module Size ( mm )	160 * 160 * 20
Module Pixels (dot)	16 * 16
3.Unit box
Module quantities in a unit box	6 (L) * 6 ( H )
Unit box size ( mm )	960 (L) * 960 (H) * 150
Unit box Pixels ( dot )	96 * 96
Unit box material	Aluminum or Iron
Unit box weight (kg)	Aluminum : 40 or Iron : 55
4.Packaging
Packing Way	Two unit boxes packed into one
Packing box material	Wooden case or Flight box
5.electricity parameter
Pixel density (dots/ m 2 )	10000
White Balance Brightness ( cd/m 2 )	≥ 6500
Color temperature ( K )	5000-9500 (choice by user)
Brightness Adjusted	100 grade by software or by Auto-optic induced.
View Angel	Horizontal 110 ° ; Vertical 70 °
Best viewing distance ( m )	16-150
Communication distance ( m )	Internet Wire : 120 Fiber Cable : 1000
Screen work Method	1/4 scan
LED driving method	Constant driving current
Gray Grades	16384 levels for each color
Display Color	4 , 398 , 046 , 511 , 104
Refresh Frequency ( Hz )	≥ 9600
Picture display method	Dots to dots display synchronized with CRT
Signal interface	DVI
Input signal	Video : PAL/NTSC optioned . VGA, Svideo, DVD, TV
Display format	800 * 600 , 1024 * 768 , 1280 * 1024
Software	Support windows series system
Protection grades	IP 65
Working temperature (ºC )	-10 +50
Humidity ( RH )	Up to 95
Stored temperature ( ºC)	-30 +70
Screen Lifetime(hours)	≥100, 000
Out of controlled dots	≤3/10, 000 (Out of controlled dots means the pixels of which the brightness and the wave length are both >10% depart to the normal one)
Whole display flatnes	Less than 1mm Juncture
Maintance way	Back-maintained or front-maintained, modules displaced
Switch power supply	Switch power supply (include CE/GS or UL/CSA certificate) 110V/60HZ , 220V/50HZ
Power Consumption ( w /m 2 )	Max : 750 , Average: ≥ 260
