SMD3528 Indoor Advertising LED Display Full Color P4.8 For Conference Room

SMD3528 Indoor Advertising LED Display Full Color P4.8 For Conference Room

SMD3528 Indoor Advertising LED Display Full Color P4.8 For Conference Room
SMD3528 Indoor Advertising LED Display Full Color P4.8 For Conference Room SMD3528 Indoor Advertising LED Display Full Color P4.8 For Conference Room SMD3528 Indoor Advertising LED Display Full Color P4.8 For Conference Room SMD3528 Indoor Advertising LED Display Full Color P4.8 For Conference Room

Large Image :  SMD3528 Indoor Advertising LED Display Full Color P4.8 For Conference Room

Product Details:
Place of Origin: China
Brand Name: YUCHIP
Certification: CE,ROHS,FCC,EMC
Model Number: IF-4.8S
Payment & Shipping Terms:
Minimum Order Quantity: 1sqm
Price: Negotiable
Packaging Details: Flight Case,Wooden Case,Strong Carton Box
Delivery Time: 15-20 Working Days
Payment Terms: T/T
Supply Ability: 5000㎡/Month
Detailed Product Description
High Light:

led video display board

,

commercial led display

SMD3528 Indoor Advertising LED Display Full Color P4.8 For Conference Room





Quick Detail:





1. LED Module Size: 240mm x 240mm;

2. LED Cabinet Size: 480mm x 480mm x 65cm;

3, LED Source: Epistar SMD2121

4  Power Supply: Ulra slim YHY and G energy;

5, Cabinet Weight: 8kg/cabinet

6. LED Cabinet Material: Extrusion Aluminum.







Description:





1, P4.8 advertising LED Screens utilize full black color LED chips;

2, High resolution: P4.8 LED video panels is being widely choose for indoor rental LED Screens project because of its high resolution;

3, Indoor P4.8 commercial LED advertising screens is being widely choose for church LED displays use because of its high resolution and cost effective;

4, P4.8 indoor LED display screens rental is of light weight for hanging up installation;

5, Ultra slim: Rental LED display is designed at 100mm thickness;

6, Fast and easy assembly: 4 set fast lockers equipped on each LED cabinet for seamless connection between cabinets;







Applications:



Concert rental LED display

Entertainment events LED screen

Stadium rental LED wall

Fash show stage LED display

Car exhibition LED display

Rental commercial LED display

Commercial Advertising Full Color LED Display
Church Full Color LED Display
Airport Advertising LED displays
Car exhibition Advertising LED displays
Conference room Advertising LED displays
Shopping Mall Advertising LED displays
Street Advertising LED Billboard
Stores LED Advertising Display







Specifications :



LED MODULE PARAMETER
Pixel pitch (mm) 4.8
Pixel configuration 3 in 1
Encapsulation SMD2121
Colors matches 6:3:1
Module resolution (pixels) 50 x 50
Module pixel 2500
Module size (mm) 240 x 240
LED CABINET SPECIFICATION
Cabinet size (mm) 480 x 480 x 85
Cabinet resolution (pixels) 100 x 100
Cabinet pixels (pixels) 10000
Cabinet material Extrusion Aluminum
Cabinet weight (kg) 8kg
LED DISPLAY SPECIFICATION
Pixel density(pixel/m2) 43264
Brightness(cd/m2) ≥1500 (adjustable)
Brightness adjusted 100 grade by software or by Auto-optic induced
View angle Horizontal 140°; Vertical 140°
Best viewing distance (m) ≥4m
Communication distance(m) <100meter by Internet Cable(without Relay; Multi mode fiber cable < 500m;
Single mode fiber cable < 20km
Display work method 1/16 Scan
LED driving method Constant driving current
Color contrast ratio 4000:1
Gray Grade 16bit
Display Color 439, 804, 651, 110
Refresh Frequency (Hz) ≥1000
Picture display method Intellective control technology , test-itself technology , correct technology,
Synchronization Control
Input signal DVI (S-VIDEO, CVBS, ,DP,HDMI,VGA, PAL/NTSC, etc.through Video processor
converting )
System operating WINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc.
Front/Rear IP Level IP43
Working temperature(ºC) -20~+60
Stored temperature (ºC) -30~+80
Operation humidity(RH) 0-95%
Display Lifetime(hours) 10 years or more( natural environment)
100000 hours( ideal environment)
Maintenance Rear side
Working Voltage AC110 / AC220V±10% 47~63HZ
Out of controlled dot ≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the
wave length are both >10% depart to the normal one)











Competitive advantages:



1, P4.8 indoor LED screens high resolution for indoor rental events that require high quality presentation;

2, PH4.8 indoor rental LED displays is being widely choose becase it would be more fast to earn back investment compared with indoor P4.8 rental LED screens.

3, Utilizing Sum driver IC to reach high refresh frequency and high grey grade;

4, Large viewing angle at 140 degree horizontal and vertical;

5, Full black color LED chips;

6, Contrast ratio up to 4000:1 to react real color of the content;



SMD3528 Indoor Advertising LED Display Full Color P4.8 For Conference Room 0SMD3528 Indoor Advertising LED Display Full Color P4.8 For Conference Room 1

SMD3528 Indoor Advertising LED Display Full Color P4.8 For Conference Room 2SMD3528 Indoor Advertising LED Display Full Color P4.8 For Conference Room 3SMD3528 Indoor Advertising LED Display Full Color P4.8 For Conference Room 4
