DIP346 P10 Customized Size Outdoor Full Color Advertising Led Display

Large Image : DIP346 P10 Customized Size Outdoor Full Color Advertising Led Display

Product Details:

Place of Origin:	China
Brand Name:	ZCLED
Certification:	CE, FCC, ROHS
Model Number:	ZCLED--P10

Payment & Shipping Terms:

Minimum Order Quantity:	1sqm
Price:	USD 650-1050 per square meter
Packaging Details:	Woodencase package or flightcase package
Delivery Time:	8-25 working days
Payment Terms:	Western Union, T/T, L/C
Supply Ability:	3000sqm/month

Contact Now

Detailed Product Description

Parameter:	ZCLED-P10	Screen Dimension:	Customed Size Based On The Project
Led Module Size:	160*160mm	Pixel Configuration:	RGB LED Display
LED Lifespan:	100,000hrs	Package:	Flight Case Or Wooden Case For OPTION

DIP346 P10 Customized Outdoor Led Advertising Display Waterproof

Features

Using mature technical traditional DIP lamp, powerful heat dispersion ,high brightness and good consistency,showing vivid video. The selection of excellent IC and controlling system of Q-Color can guarantee the exquisite displaying effects. Minimum viewing distance is about 10m.

Product details:

DIP Cabinet

P10mm DIP 346 Full Color Outdoor Led Screens IP65 with 160*160mm Module and Vertical 140°

Parameter	ZCLED-P10
LED lamp	DIP 346
Pixel pitch (mm)	10
Pixel density(pixel/sq.m)	10000
Pixel configuration	1R1G1B
Driving mode	¼ scan
Module size (mm ,w x h)	160*160
Resolution(WxH)	16*16
Viewing angle(° )	Vertical140° Horizontal140°
Optimum viweing distance(m)	10+
Gray scale (bit)	≥12
Brightness(cd/m2)	≥7500
Refresh rate(hz)	≥800HZ
Power supply	5V,DC
Lifespan(hrs)	100,000＞lifespan＞40,000
Cabinet size(mm,wxh)	960*960
Cabinet resolution(wxh)	96*96
Cabinet material	Metal/Aluminum
Colors	Black computer grey Sony grey
Maintenance mode	Front/rear maintenance
Ingress protection	IP65
Cabinet power supply	110-220V(+-10%),AC, 50hz/60hz
Power consumption(w)	Max700w/sqm Avg 210w/sqm
Working temperature( ℃ )	-30~50
Storing temperature( ℃ )	-40~80
Evaluated weight(kg/m2)	Fe: 60 Al: 45
Communicate signal	Twisted-pair(network)
