Product Details:
Payment & Shipping Terms:
|
| Usage: | Outdoor | Tube Chip Color: | Full Color |
|---|---|---|---|
| Display Function: | Video | Pixels: | 10mm |
| Brightness: | 6000 To 8000cd/sqm | Protection Leve: | IP65 |
| Led Chip: | Epistar/Slian | RGB: | 2R1G1B / 1R1G1B |
| High Light: | led screen advertising,led display board for advertising |
||
P8 P10 P16 P20 Good Quality Outdoor Led Advertising Screen Price with Good Quality
· Pixel Configuration: DIP 1R1G1B
· Pixel Pitch: 10.667mm
· Module Resolution: 24 × 24 pixel dots
· Module size: 256mm x 256mm
· Cabinet Resolution: 96 × 72 pixel dots
· Cabinet Size: 1024 x 768 x 185 (mm)
· Cabinet Weight: 41kg
Features:
· Louvered-face and mask-face panels are avaiable.
· The whole sign is separated into pieces for transportation.
· Modular Design allows the sign to be built in various size.
· LED module is sealed twice for good weather resistance.
· Forced air ventilation and natural heat-dissipation system.
· Easy access from double-layer weather-resistant rear doors.
|
Parameter |
Unit |
Value |
|
Brightness |
nits |
7000nits |
|
Color temperature |
deg.k |
6500 |
|
Viewing angle - Horizontal |
deg. |
120(60/ minus 60) |
|
Viewing angle - Vertical |
deg. |
60(30/ minus 30) |
|
Cabinet Weight |
kg |
41 |
|
Cabinet Width |
mm |
1024 |
|
Cabinet height |
mm |
768 |
|
Cabinet depth |
mm |
185 |
|
Cabinet area |
sq. m. |
0.79 |
|
Cabinet material |
|
Aluminium |
|
Aspect ratio |
|
6 : 5 |
|
Ingress Protection (Front/Rear) |
IP |
IP65/IP21 |
|
Operating temperature range |
deg. C |
-20 to 50 |
|
Operating Humidity range |
HR |
10% to 90% |
|
Pixel type and configuration |
R/G/B |
1,1,1 |
|
Pixel pitch |
mm |
10.667 |
|
Pixel matrix per cabinet |
|
96 x 72 |
|
Pixels per cabinet |
|
6912 |
|
Lines per meter |
|
94 |
|
Pixels per sq. meter |
|
8789 |
|
LEDs per sq. meter |
|
26367 |
|
Recommended minimum viewing distance |
m |
11 |
|
Colours |
|
1.07Billion |
|
Gray scale |
Levels |
1024 levels per colour |
|
Brightness control |
Levels |
100 |
|
Digital processing |
bit |
10 |
|
Frame rate |
Hertz |
60 |
|
Display refresh rate |
Hertz |
≥400 |
|
Scan mode |
|
1/4 duty scan driv |
|
Input voltage |
VAC |
110 to 240 |
|
Input power frequency |
Hertz |
50 or 60 |
|
Input power (max/avg) |
Watts per sq.m |
600/250 |
