Outdoor p14 full color Advertising LED Display SMD module Cabinet Ultra Thin

Large Image : Outdoor p14 full color Advertising LED Display SMD module Cabinet Ultra Thin

Product Details:

Place of Origin:	Shenzhen ,China
Brand Name:	LanGao
Certification:	CE/ROHS/FCC/UL/ISO/3C
Model Number:	LGP14

Payment & Shipping Terms:

Minimum Order Quantity:	1sqm. / 1 piece
Packaging Details:	Plywood or Flight Case
Delivery Time:	10-20 days
Payment Terms:	T/T ,L/C ,Paypal or

Contact Now

Detailed Product Description

Usage:	Outdoor	Tube Chip Color:	Full Color
Display Function:	Video	Pixels:	14mm
Brightness:	6000 To 8000cd/sqm	Protection Leve:	IP65
Led Chip:	Epistar/Slian	RGB:	2R1G1B / 1R1G1B
High Light:	led advertising billboards , led display board for advertising

Outdoor p14 full color smd module Advertising LED screens Display Cabinet Ultra Thin

P14 Advertising LED screens Displayadopts physical and virtual pixel technology which makes the picture more clear and vivid, no flicker and blind dots. The Advertising LED screens Display is manufactured in a waterproof and dustproof design so it can work very well under rain and sunshine. It can be assembled, disassembled and repaired very easy, it is an ideal product for any kind advertisements. Wide application field: advertising LED display, stadium perimeter LED display, mobile led display for mobile media, shopping mall LED display for logo showing, bank & stock exchange LED display for rates showing, train & bus station, airport, telecommunication LED screen system for information showing and instruction, stage performances and so on.

Features:

1) Reliable quality, advanced and mature technology, compliant with industrial
standards and technology developing trend
3) Good heat emission, water proof and stable performance
4) Audio and video interface of the system can offer vivid, complete and high
quality LED display to TV broadcasting signal
5) High resolution and definition of screen image, clear and non-flash screen
6) Supports video and radio frequency input, special structure can be freely
assembled
7) Widely used in stadium, bank, restaurant, station, shopping center,
government, schools, entertainment, and enterprise

	Specification	PH14
1	Pitch	14mm
2	Module Resolution	16×8=128 (dot)
3	Module Size	224mm ×112mm
4	Module Quantity/cabinet	24(Pcs)
5	Cabinet Size	896mm×672mm
6	Resolution/cabinet	64×48(dot)
7	Density	5102(dot/s.q.m)
8	LED Driving method	Constant driving / 1/2 Scan
9	LED Standard	DIP546
10	Viewing Angle (H/V)	H:100±5°V:45°
11	Brightness	≥7000CD/s.q.m
12	The Optimal viewing distance	15-200m
13	Display Colors	687(million)
14	Pixel configuration	1R1G1B
15	Protection Degree	65(IP)
16	Power	(Max.Consumption): True pixels:1000 W/s.q.m
16	Power	(Average Power): True pixels:450 W/s.q.m
17	Control mode	Video Sync
18	Display Mode	(Max)1024×768/1280×1024
19	LED Parametres	(R):λd (619~624nm)IV: (460~510mcd)
		(G):λd (520~524.5nm)IV: (2000~2300mcd)
		(B):λd (468.5~472.5nm)IV:(490~540mcd)
20	Rate	≥300Hz
21	Communication	1000M Cats(≤120M)/Fiber optical (10.000m)

Product Advantages:

1) Price Advantage: Best competitive price of the market.
2) Performance Advantage: Best brightness, High refresh rate, high consistency, Big viewing angle...

3) Quality advantage: From material to finished product, from design to produce, we control all steps, that's the guarantee of the quality and reliability.
