Product Details:
Payment & Shipping Terms:
|
| Usage: | Outdoor | Tube Chip Color:: | Full Color |
|---|---|---|---|
| Display Function: | Video | Pixels:: | 10mm |
| Brightness:: | 6000 To 8000cd/sqm | Protection Level:: | IP65 |
| High Light: | outside led screen,led outdoor advertising board |
||
SMD3535 super bright waterproof large full color p10 outdoor led display screen
P10 outdoor LED display adopts physical and virtual pixel technology which makes the picture more clear and vivid, no flicker and blind dots. The screen is manufactured in a waterproof and dustproof design so it can work very well in rain and sunshine. It can be assembled and disassembled very easy, and it is an ideal product for any kind advertisements.
The outdoor led display characterized by perfect vivid image, super brightness, high refresh rate, long life span and stable work, and waterproof, etc.
It is widely used in advertising, sports, industrial enterprise, transportation, stations, terminals, airports, construction, education system and other public places.
|
Pixel pitch |
10mm |
|
Pixel density |
10000 pixels/m² |
|
Power consumption |
Average 200W/m² |
|
Module size |
160mm × 160mm (32 pixels × 32 pixels) |
|
Single panel dimension |
0.768m(W) × 1.92m(H) |
|
Pixel configuration |
Tri-color RGB LEDs |
|
Power supply |
Power input: AC100V to 240V Operating voltage: DC5V |
|
Transparent rate |
5% |
|
Display port |
DVI/HDMI |
|
Display mode |
Synchronous to video source |
|
Scan mode |
1/4 |
|
Screen resolution |
1024 × 768, max 1280 × 1024 |
|
Brightness |
1800/3600/6800nits |
|
Viewing angle |
120° |
|
Thickness |
11mm |
|
Data refresh rate |
12000Hz |
|
Colors |
16.7 million (R 256, G 256, B 256) |
|
Ingress protection |
IP43/IP54 |
|
Operating temperature |
-30°C ~ 60°C |
|
Humidity |
10% ~ 90% |
|
Weight |
10kg/m² |
|
Hanging method |
Hanging type |
Main advantages:
1. New mask design makes LED light almost zero reflection, which ensures the screen displaying effect;
2. The cabinet of unit modules adopts to high-temperature spraying technology, the antirust function is greatly improved;
3. Module surface flatness ± 0.2mm, the entire screen has good flatness;
4. High uniformity display color;
5. For improving the service life, PCB is made by wave soldering process with the green oxygen isolation layer, whichprevents the line of moisture and oxidation.
6. Service efficiency of the screen switch power supply is increased substantially, which reduces power failure rate;
7. Using fishbone bus line greatly reduces the contact problem;
8. IP65 grade for high performance waterproof and dustproof capability;
9. -25°C – 65°Cworking environment for outdoor display, adapted to the harsh environment.
