High Definition 2R1G1B LED Outdoor Advertising Board 6000 to 8000 cd / sqm

Large Image : High Definition 2R1G1B LED Outdoor Advertising Board 6000 to 8000 cd / sqm

Product Details:

Place of Origin:	Shenzhen ,China
Brand Name:	LanGao
Certification:	CE/ROHS/FCC/UL/ISO/3C
Model Number:	LGP16

Payment & Shipping Terms:

Minimum Order Quantity:	1sqm. / 1 piece
Packaging Details:	Plywood or Flight Case
Delivery Time:	10-20 days
Payment Terms:	T/T, L/C, ,Paypal

Contact Now

Detailed Product Description

Usage:	Outdoor	Tube Chip Color::	Full Color
Display Function:	Video	Pixels::	16mm
Brightness::	6000 To 8000cd/sqm	Protection Level::	IP65
High Light:	outside led screen , led outdoor advertising board

P16 Advertising Sport Stadiums Outdoor LED Display Solutions High Definition 2R1G1B

Outdoor LED Display installed in stadium for celebrating the birthday of Thailand Queen, with it's good LED screen performance, good color uniformity, favorited by large people.
With High brightness >7500 nits make the display content visible even under direct sunshine during daytime.
With light sensor for automatic brightness adjustment, make the brightness suitable for people’s eyes and save electricity cost, more environment Friendly.
Anti-UV mask, IP65 waterproof design, total outdoor use application.
Large viewing angle , full color, high color uniformity and clear image, bring you a vivid audio visual effect.
Epistar, Silan, Cree, Nichia, etc LED chip available.
With ETL, CE, EMC, TUV, ISO, ROHS, SO14001, ISO9001 certificates.
P4, p5, p6, p8, p10, p12, p16, p20, p25, etc indoor and outdoor SMD, DIP all available.
Widely used for gas station, stations, shopping mall, square plaza, stadium, street advertising, restaurant, shops etc.
NOVA, DBSTAR, LINSN, COLORLIGHT LED control system available.

Technical Specs

Pixel pitch(mm)	16	16
LED type	DIP246	SMD3535
Pixel configuration	1R1G1B	1R1G1B
Module size(mm)	256*128	256*128
Module resolution	32*16	32*16
Cabinet size (w x h)	1024*768mm	1024*768mm
Cabinet resolution	128*96	128*96
Cabinet material	Steel/Al	Steel/Al
Cabinet weight (Kg/Sqm)	60/52	60/52
Brightness(cd/m2)	>7500	> 5000
Viewing angle(°)	(H)110° (V)60°	(H)140° (V)140°
Driving mode	1/4 scan	1/4 scan
Refresh frequency (HZ)	>1000	>1000
Operation temperature	-30°C~+60°C	-30°C~+60°C
Operation Humidity	10%~99%	10%~99%
Input voltage	220V±15% /110V±15%	220V±15% /110V±15%
Max Power consumption (w/m2)	<800	<900
Ave. Power consumption (w/m2)	<240	270
Life span	100,000hours	100,000hours
Protection level	IP65	IP65

1) With good lightening accordance and no mosaic
2) Can play different formats of image files, flash, WAV/MIDI, video signal from
TV, video signal from video and other equipment
3) Different video frequency can be changed freely at the same time, and the image
can be enlarged and reduced
4) High brightness, and can be adjustable, meets the need of changing requirement
of customer in environment
5) Uses real pixels rather than virtual pixels, better viewing effect

6) light and easy to install and move
