Programmable Electronic P10 Full Color Outdoor Led Display 10000 dots / m2 Density

Programmable Electronic P10 Full Color Outdoor Led Display 10000 dots / m2 Density

Programmable Electronic P10 Full Color Outdoor Led Display 10000 dots / m2 Density
Programmable Electronic P10 Full Color Outdoor Led Display 10000 dots / m2 Density Programmable Electronic P10 Full Color Outdoor Led Display 10000 dots / m2 Density

Large Image :  Programmable Electronic P10 Full Color Outdoor Led Display 10000 dots / m2 Density

Product Details:
Place of Origin: Shenzhen ,China
Brand Name: LanGao
Certification: CE/ROHS/FCC/UL/ISO/3C
Model Number: LGP10
Payment & Shipping Terms:
Minimum Order Quantity: 1sqm. / 1 piece
Packaging Details: Plywood or Flight Case
Delivery Time: 10-20 days
Payment Terms: T/T, L/C, ,Paypal
Detailed Product Description
Usage: Outdoor Tube Chip Color:: Full Color
Display Function: Video Pixels:: 10mm
Brightness:: 6000 To 8000cd/sqm Protection Level:: IP65
High Light:

outside led screen

,

led outdoor advertising board



High density P10 Full Color Programmable Electronic Outdoor Led Display



waterproof, lightning protection, radiation proof,

-high brightness, good stability,

-rich colors, large area display, long life

-multi-choice cabinets (waterproof cabinets, simple box, die-cast box)

-asynchronous or synchronous control



2.Features :



· With super-high brightness LED, high contrast

· High frame frequency, wider view angel

· With module development and distributed scan

technology, high reliability

· Universal AC input / full range

· IP65 protection level, outdoor solution

· PC synchronous or asynchronous control(optional)

· Use common video play software, easy to use





Item

Specification Parameter

Pixel type

Real full color

Pixel color

RGB

Module size

320*320mm

Pixel led

DIP346

Pixels pitch

10mm

Resolution rate

32*32

Driving way

1/4

Driving IC

MBI5024

Working voltage

DC5V

Power

80W

Working temperature

-30°C - +50°C



4.Screen Specification



Item

Specification

Material

Aluminum

Color

Black

Size

960*960mm

Resolution rate

96*96

Module quantity

3*3

Density

10000dots/m2

White balance luminance

7000-11000cd/m2

Color temperature

6500

Horizontal view angel

110

Vertical view angel

50

Protection grade

 Before/after: IP67/IP65

Non-Flatness

<1mm

Module interval

<1mm

Weight

40kg

Maximal power/m2

750W

Frame frequency

≥60Hz/s

Refresh frequency

800-3840Hz

Gray grade

1024*1024*1024Grade/1073741824

Luminance adjusted

256 grade by auto-optic/color &8 grade by hand

Input signal

RF,S-video,RGB,RGBHV,YUV,YC&Composition,etc

MTBF

>5000h

Life-span

>100000h

Speckles rate

<0.0001





Advantages for the p10 outdoor led display



1. Cabinet and modules hollow are designed for great heat dissipation performance, high transparency, and high wind resistance level.

2. Light weight and small size: each cabinet size only 640mm*640mm*98mm, weight 12.8kg, frame 55mm.

3. Wide application: it can be used for any rental application of stage show: such as main screen, side screen, floor screen, arc screen stage design etc.

4. Front maintenance module structure design, modules can be installed and dismantled from front side, any cabinet within this screen is free of assembly and dismantling.
5. Easy and Fast: for both installation and dismantling, without any tools, it takes only 10 seconds to assembly, hanging, pile up and fix installation available.
6. High structure performance: easy connection of each components, modules and HUB card without flat cables, modules and systems without power cable.


Programmable Electronic P10 Full Color Outdoor Led Display 10000 dots / m2 Density 0
