Business, retail management; Logistics supply chain management;
Library management; Mail management; Blood bank management; Drugs management;
Storage management; Production flow management; Enterprise fixed asset management; Livestock management;
Commodity security; Special management items (weapons, pressure containers, etc.); Banking, insurance, customs,
railways, military, security and other fields.
Laser barcode reader module——650nm laser, Support barcode types: UPC-A, UPC-E, industrial 2 of 5, interleaved 2 of 5,
EAN8, EAN13, code 128 EAN 128, code 39 code93, codabar125; resolution (pcs0.9); 0. 10mm(4mil); depth of field:
10-420mm(pcs0.9, density0.25); read breadth: 60mm at 30mm(from object), 98mm at 100mm(from object);
read speed: 74/s; read precision: 0.10-0.825mm; read distance: 10-520mm; code error rate: 1/1000000.
2.(Optional)support tags in accordance with ISO15693, such as I-CODEⅡ series,
PicoTag of INSIDE series and Tag-it of TI series.
3.(Optional)support contactless smart cards in accordance with ISO14443 Type A/B, such as Mifare1 series Ultralight,
Mifare1(S50), Mifare4(S70), MifarePro,DESfire and so on.
4.(Optional)a standard SAM socket,support contact smart cards in accordance with ISO7816.
5.(Optional)GPRS module-----working frequency: EGSM: 900/1800MHZ; GSM: 850/190MHZ; support TCP/IP: support SMS.
Processor |
32-bit CPU |
Memory |
Flash Memory:16Mbit(can be extended to 32Mbit or 64Mbit), DRAM:16Mbit |
Display |
128*128 dot,EL backlight,8*8lines Chinese characters(16*16lines western characters), one line icons |
Keypad |
28 keys with backlight |
IC card interface |
one outlay interface,support RS-232 serial, one IrDA interface |
Battery system |
1700mAH recharge lithium battery;And a button battery fixed in main board to keep the clock |
Quiver function |
Yes |
Buzzer |
Yes |
Working environment temperature |
-20℃~50℃ |
Relatively humidity |
45%RH~85%RH(no coagulate dew) |
Power |
Average <0.5W,max<3.5W |
