Product Details:
Payment & Shipping Terms:
|
| OS: | Android 8.1 OS | RAM: | 4GB |
|---|---|---|---|
| ROM: | 64GB | CPU: | Octa-core 2.0Ghz |
| Dimension: | 174*82*33mm(the Thickest Part 56mm) | Weight (with Battery): | 460g |
| High Light: | Mobile POS Terminal,IP65 Barcode Scanner |
||
Handheld GPRS Mobile Handheld Terminal / Portable Thermal Printer RFID Reader
| SD60PRT Basic Parameters | ||
| OS | Android 8.1 | |
| CPU | Octa-Core 2.0GHz | |
| RAM | 4GB | |
| ROM | 64GB | |
| Expansion | Micro SD (TF) card slot up to 128GB | |
| Keypad | 5 side buttons: 2 volume buttons,2 function buttons(1 left and right),1 power button | |
| Notification | Sound/vibration/LED prompt | |
| Audio | Front dual stereo speakers Volume 90db±3db(test distance 10cm) |
|
| Dimentions | 174*82*33mm(the thickest part 56mm) | |
| Weight( with battery) | 460g | |
| Camera | ||
| Camera | Rear camera 13MP AF+High brightness LED flash+Front Camera 5MP FF | |
| Focus mode | Autofocus ; Fixed focus | |
| Display | ||
| Display | 6.0 inch IPS high light screen | |
| Resolution | 2160*1080 | |
| Touch Panel | 5-point capacitive touch screen | |
| Power | ||
| Battery | Large-capacity Removable Li-ion Battery 29.6Wh | |
| Charging | PE fast charging, full charging time< 4 hours | |
| Interface | 2micro SIM cards 1micro SD card slot up to 128GB USB-Type C support fast charging,OTG, Support fast charging5V/9A 1.67, charging and bottom USB connector |
|
| Communication | ||
| Bluetooth | BT4.1 BLE | |
| WLAN | WiFi 802.11 a/b/g/n 2.4G 5G dual frequency | |
| WWAN | FDD-LTE B1/B3/B5/B7/B8 TDD-LTE B38/B39/B40/B41 TDSCDMA B34/B39 WCDMA B1/B2/B5/B8 GSM B2/B3/B5/B8 CDMA1x/CDMA2000 BC0/BC1 |
|
| GPS Positioning Module | GPS+BD+GLONASS | |
| Performance | ||
| Operation Temperature | -20℃ ~55℃ | |
| Storage Temperature | -30℃ ~+70℃ | |
| Humidity | 5%~95%(No condensation) | |
| Sealing | IP54 | |
| Drop Test | 6 sides can withstand the impact of 1.2 meters drop to the concrete floor | |
| ESD | ±15kV Air Discharge, ±8kV Contact Discharge | |
| Certificate | CCC,CE,ROHS,FCC,BIS | |
| Extensibility | ||
| NFC | Support agreement:ISO14443A/B, ISO15693 reading distance: 0~5cm |
|
| Printer | 2 inch adhesive printer,Support adhesive and thermal printing,The print head has a lifetime of 50KM,Roll diameter 40mm, speed 80mm/s |
|
| Code scanning Support code system |
CM60, Support code system:EAN13 EAN8, UPCA, UPCE, Code 128, Code 39 Codabar, UCC/EAN128, RSS,ITF, ITF14, ITF6 ISSN, ISBN, Standard 25, Matrix 25 Industrial 25,Plessey, MSI Plessey, Code 11 Code 93, PDF417, QR Code, DataMatrix AZTEC, Hanxin Code, Maxicode, Micro QR Micro PDF417, Composite |
|
| PSAM | Support | |
| Sensor | Geomagnetism, acceleration, optical distance | |
| Optional Accessories | DC60PRT Single charging base | Charging input: 9V 2A |
| texture of material: PU |
||
FAQ
Question 1: What's your MOQ?
The MOQ of barcode scanner handheld PDA is 1 piece.
Question 2: How long is the delivery time?
The delivery time of barcode scanner goods is different from quantities:
If 1~100 pcs, It's about 5--10 working days;
If 100~500 pcs, it's about 10--20 working days;
If More than 500 pcs, It's about 20-30 working days.
Question 3: Would you like to supply 1 sample for testing?
Yes, Of course. We can provide 1 sample Terminal PDA for your testing.
Question 4: What's the total price for 1 sample?
As a manufacturer of barcode scanner terminal PDA,the more you buy, the cheaper it'll be.
The sample price is a little bit higher than the common wholesale price excluding the freight fee.
Question 5: Are you a manufacturer of Handheld PDA?
Yes, we are a R&D orientation China Listed Company, mainly producing industrial PDA Terminal Hardware and as a software solutions supplier with over 8 years' OEM/ODM experience. We are also cooperating with Foxconn Factory.
Question 6: What kind of services do you support ?
We provide you Free SDK and Technical Support for your Barcode Scanner.
We also provide ODM/OEM Customization Services based to your demands.
We support 13 months Warranty for all the device and 6 months for the batteries. Exend warranty, it costs 10% at the first year, and 15% for the second year.
Question 7: What's for payment term and delivery term ?
It's generally 30%-100% TT in advance for all orders. Meanwhile, Paypal or West Union is acceptable.
FOB Shenzhen as Trade Term.
Question 8: Who are your customers?
Our products have been sold to worldwide,especially market in South/North America, Europe, Asia, Africa Mid-east, etc.
The market share is increasing quickly every year and we get more and more positive feedbacks from our customers.
