Product Details:
Payment & Shipping Terms:
|
| High Light: | data collection terminals,mobile card terminal |
||
|---|---|---|---|
Specifications:
| Hardware | ||
| Core board | ||
| WM6.1/6.5 OS | option1 | Marvell PXA310(806MHz)+qualcomm (GSM band 900/1800/1900MHz, GPRS, EDGE/WCDMA 2100MHz HSDPA 3.6Mbps |
| WM6.1/6.5 OS | option2 | Marvell PXA310(806MHz)+qualcomm EVDO (800MHz, CDMA 1X, EVDO) |
| android 2.3 OS | yes | Marvell PXA910(806MHZ) +GSM Quad-band 850/900/1800/1900MHz, GPRS, EDGE/WCDMA900/1700/2100MHz HSDPA 3.6Mbps |
| Memory | Flash ROM | 256MB |
| RAM | 256MB DDR | |
| Extend Slot | Micro SD 16G (SDHC) | |
| Motherboard | ||
| Display | 3.2inch TFT LCD display (320 x 240) 65k color/touch panel/ Transflective screen | |
| Form Factor | Bar type classical Pocket PC,Industrial appearance | |
| GPS Solution | Ublox The 5th Generation | |
| Wire Transmission | USB 2.0 Full Speed, charging/sync | |
| Bluetooth | Bluetooth SIG version 2.0 compliant; Supported profiles: headset, hands-free, object push, serial port, dial-up network | |
| WiFi | WiFi (802.11 b/g) | |
| RFID | yes | HF RFID RF30 (ISO 14443A/B) |
| option 2 | HF RFID RF60 (ISO 14443A/B ISO 15693) | |
| Barcode Scanner | option 1 | 1D Infrared scanner (NewLand:EM1300) |
| yes | 1D Laser scanner (Symbol:SE9551) | |
| option 3 | 1D Laser scanner (Honey:N4313) | |
| option4 | 2D Barcode scanner (SE4500SR) | |
| GPS | option 1 | UBLOX LEA-6S |
| option 2 | UBLOX LEA-6T | |
| option 3 | UBLOX LEA-6N | |
| C-MOS imager | 5M AF | |
| External Interface | RS232;SPI;print | |
| Protection class | IP54 | |
| Drop resistance level | 1.5m | |
| Audio | Handfree | Yes |
| StereoBlueTooth earphone | Yes | |
| Ringtone | support 64-chord MIDI, MP3, WMA, WAV | |
| Playback | support MIDI, MP3, WMA, WAV, AMR | |
| Speaker | support handfree | |
| Network Led | red/green/yellow | |
| Keypad | Front | Number key, Function key |
| Side | Volume up, Volume down,camera | |
| Interface | Mini-USB connector | USB2.0 connection and power charging |
| SIM card slot | Yes | |
| Audio Jack | NO | |
| Battery | Type | rechargeable Li-ion battery 3000mAh |
| Standby Time | 500hours | |
| Calls Time | Up to 6hours | |
| Charging Time | 4 hours | |
| Physical Characteristics | Dimension | 149*72*28mm |
| Weight | TBC | |
| Key Software | ||
| Operating System | Windows Mobile 6.1/6.5 professional /Android 2.3 OS | |
| KVM | JAVA MIDP 2.0 | |
| Default language | English | |
| Package Contents | ||
| Standard Packaging: Main Unit*1pc, Charger*1pc, USB Cable*1pc, battery*1pc, Case*1pc, Strap*1pc | ||
