Rental Module P10 1RGB Full Color Advertising LED Display With Steel Cabinet

Rental Module P10 1RGB Full Color Advertising LED Display With Steel Cabinet

Rental Module P10 1RGB Full Color Advertising LED Display With Steel Cabinet
Rental Module P10 1RGB Full Color Advertising LED Display With Steel Cabinet Rental Module P10 1RGB Full Color Advertising LED Display With Steel Cabinet Rental Module P10 1RGB Full Color Advertising LED Display With Steel Cabinet Rental Module P10 1RGB Full Color Advertising LED Display With Steel Cabinet

Large Image :  Rental Module P10 1RGB Full Color Advertising LED Display With Steel Cabinet

Product Details:
Place of Origin: China
Brand Name: YUCHIP
Certification: CE,ROHS,FCC,EMC
Model Number: OF-10D
Payment & Shipping Terms:
Minimum Order Quantity: 1sqm
Price: Negotiable
Packaging Details: Flight Case,Wooden Case,Strong Carton Box
Delivery Time: 15-20 Working Days
Payment Terms: T/T
Supply Ability: 5000㎡/Month
Detailed Product Description
High Light:

high definition led display

,

led video display board

Rental Module P10 1RGB Full Color Advertising LED Display With Steel Cabinet



Quick Detail:


1, P10 advertising LED displays is of high resolution;
2, P10 outdoor LED screens is of low Price;
3, Large LED Module: 320mm x 320mm;
4, P10 LED Panels Cabinet: 960mm x 960mm x 150mm;
5, Both fixed and rental LED screens use;
6, 10000 pixels per square meter;



Description:


1, PH10 outdoor LED displays is utilizing both external and internal signal and power connection for stable connection;
2, Short best view distance,for outdoor P10 LED screens,the best view distance is above 8 meters; Audience/potential consumers people passed by would enjoy a clear image that standing above 8 meters;
3, P10 full color LED video screens is being widely choose for large size outdoor LED billboards projects;
4, Standard outdoor LED cabinet of IP65,waterproof and dustproof;
5, P10 LED advertising display screens is being widely installed as shoppling mall LED screen displays, rental LED video wall etc.
6, Outdoor P10 LED screen is utilizing high brightness Epistar LED chips to reach up to 8000cd/㎡. The P10 LED video displays present a clear and vivid image, even under direct sunshine;




Applications:

Commercial Advertising Full Color LED Display
Church Full Color LED Display
Road Show Full Color LED Display
High Speed Way Full Color LED Display
Airport Advertising LED displays
Train station Advertising LED displays
Entertainment Bar Advertising LED displays
Stadium Advertising LED displays
Museum Advertising LED displays
Car exhibition Advertising LED displays
Conference room Advertising LED displays
Shopping Mall Advertising LED displays
Street Advertising LED Billboard
Stores LED Advertising Display
Office Building LED advertising Screens
Roof Building Outdoor LED Display Screens




Specifications :

LED Module Parameter
Pixel pitch (mm)10
Pixel configuration1R1G1B
EncapsulationDIP346
Colors matches6:3:1
Module resolution (pixels)32 x 32
Module pixel1024
Module size (mm)320 x 320
LED CABINET SPECIFICATION
Cabinet size (mm)960 x 960 x 150
Cabinet resolution (pixels)96 x 96
Cabinet pixels (pixels)9216
Cabinet materialSteel
Cabinet weight (kg)50
LED DISPLAY SPECIFICATION
Pixel density(pixel/m2)10000
Brightness(cd/m2)≥8000 (adjustable)
Brightness adjusted100 grade by software or by Auto-optic induced
View angleHorizontal 110°; Vertical 70°
Best viewing distance (m)≥8m
Communication distance(m)<100meter by Internet Cable(without Relay; Multi mode fiber cable < 500m; Single mode
fiber cable < 20km
Display work method1/4 Scan
LED driving methodConstant driving current
Color contrast ratio1800:1
Gray Grade16bit
Display Color439, 804, 651, 110
Refresh Frequency (Hz)≥600
Picture display methodIntellective control technology , test-itself technology , correct technology, Synchronization
Control
Input signalDVI (S-VIDEO, CVBS, ,DP,HDMI,VGA, PAL/NTSC, etc.through Video processor converting )
System operatingWINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc.
Front/Rear IP LevelIP65
Working temperature(ºC)-20~+60
Stored temperature (ºC)-30~+80
Operation humidity(RH)0-95%
Display Lifetime(hours)10 years or more( natural environment) 100000 hours( ideal environment)
MaintenanceRear side
Working VoltageAC110 / AC220V±10% 47~63HZ
Power consumptionMax: 940W/㎡ ; Ave:400W/㎡
Out of controlled dot≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wave
length are both >10% depart to the normal one)





Competitive advantages:

1, P10 1RGB LED screens outdoor seamless connection: 320mm x 320mm large size LED module makes LED display seamless connection in one cabinet;
2, LED Display P10 1RGB Outdoor Screen Advertising large Epistar chip guaranteeing up to 10000 nits brightness to deliver vivid image and video even under direct sunshine;
3, P10 LED display screen boards spare parts are of best quality components, like Epistar LED chips, MBI5020, MBI5024 IC driver, Meanwell power supply and Neutric power and signal connectors etc.;
4, Better waterproof, PCB is painted few layers coating for dust-proof,moisture proof and anti-corrosion;
5, PH10 full color LED advertising sign billboards is of high contrast ratio at 4000:1, thus LED panels are displaying an active and true color LED advertising effect;
6, 5000㎡ per month production capacity to support timely delivery of advertising LED display screen order;
Rental Module P10 1RGB Full Color Advertising LED Display With Steel Cabinet 0Rental Module P10 1RGB Full Color Advertising LED Display With Steel Cabinet 1Rental Module P10 1RGB Full Color Advertising LED Display With Steel Cabinet 2Rental Module P10 1RGB Full Color Advertising LED Display With Steel Cabinet 3Rental Module P10 1RGB Full Color Advertising LED Display With Steel Cabinet 4
