Church Indoor P4 Advertising Led Display with SMD2020 Lisn control

Church Indoor P4 Advertising Led Display with SMD2020 Lisn control

Church Indoor P4 Advertising Led Display with SMD2020 Lisn control
Church Indoor P4 Advertising Led Display with SMD2020 Lisn control Church Indoor P4 Advertising Led Display with SMD2020 Lisn control Church Indoor P4 Advertising Led Display with SMD2020 Lisn control Church Indoor P4 Advertising Led Display with SMD2020 Lisn control

Large Image :  Church Indoor P4 Advertising Led Display with SMD2020 Lisn control

Product Details:
Place of Origin: China
Brand Name: YUCHIP
Certification: CE,ROHS,FCC,EMC
Model Number: IF-4S
Payment & Shipping Terms:
Minimum Order Quantity: 1sqm
Price: Negotiable
Packaging Details: Flight Case,Wooden Case,Strong Carton Box
Delivery Time: 15-20 Working Days
Payment Terms: T/T
Supply Ability: 5000㎡/Month
Detailed Product Description
High Light:

high definition led display

,

commercial led display

Church Indoor P4 Advertising Led Display with SMD2020 Lisn control





Quick Detail:





1. LED Module Size: 240mm x 240mm;

2, SteelLED cabinet;

3. LED Source: SMD2020

4. LED Cabinet Size: 480mm x 480mm x 90cm;

5, Cabinet Weight: 8kg/cabinet

6. Lisn control software;









Description:





1, P4 SMD2121 advertising LED display screens is of large viewsing angle at 140 degree horizontally and vertically;

3, High refresh frequency: This ensure P4 indoor LED video screens suitable for rental projects with Live broadcast,without water wave and shake.

3, P4 full color indoor LED Display screens is utilizing full black color LED chips to reach pure and true color effect;

4, High resolution: P4 LED video panels is being widely choose for indoor advertising LED Screens project because of its high resolution;

5, Seamless connection: Indoor full color LED video screens cabinet surface is uniform;

6, Ultra slim: P4 full color LED indoor displays is designed at 95mm thickness for convenient installation when space is limited;









Applications:





Entertainment Bar Indoor Full Color LED Screen

Stadium Indoor Full Color LED Display

Museum Full Color Indoor LED display

Car exhibition LED display

Conference room Indoor Full Color LED Video Display

Shopping Mall Indoor Full Color LED display

Airport Full Color Indoor LED displays

Train station Indoor Full Color LED Displays









Specifications :



LED MODULE PARAMETER
Pixel pitch (mm) 4
Pixel configuration 3 in 1
Encapsulation SMD2121
Colors matches 6:3:1
Module resolution (pixels) 60 x 60
Module pixel 3600
Module size (mm) 240 x 240
LED CABINET SPECIFICATION
Cabinet size (mm) 480 x 480 x 65
Cabinet resolution (pixels) 120 x 120
Cabinet pixels (pixels) 14400
Cabinet material Extrusion Aluminum
Cabinet weight (kg) 6.5kg
LED DISPLAY SPECIFICATION
Pixel density(pixel/m2) 62500
Brightness(cd/m2) ≥1500 (adjustable)
Brightness adjusted 100 grade by software or by Auto-optic induced
View angle Horizontal 140°; Vertical 140°
Best viewing distance (m) ≥3.5m
Communication distance(m) <100meter by Internet Cable(without Relay; Multi mode fiber cable < 500m;
Single mode fiber cable < 20km
Display work method 1/16 Scan
LED driving method Constant driving current
Color contrast ratio 4000:1
Gray Grade 16bit
Display Color 439, 804, 651, 110
Refresh Frequency (Hz) ≥1000
Picture display method Intellective control technology , test-itself technology , correct technology,
Synchronization Control
Input signal DVI (S-VIDEO, CVBS, ,DP,HDMI,VGA, PAL/NTSC, etc.through Video processor
converting )
System operating WINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc.
Front/Rear IP Level IP43
Working temperature(ºC) -20~+60
Stored temperature (ºC) -30~+80
Operation humidity(RH) 0-95%
Display Lifetime(hours) 10 years or more( natural environment)
100000 hours( ideal environment)
Maintenance Rear side
Working Voltage AC110 / AC220V±10% 47~63HZ
Out of controlled dot ≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the
wave length are both >10% depart to the normal one)









Competitive advantages:





1, Indoor full color PH4 LED video screens contrast ratio up to 4000:1 to react real color of the content;

2, Pixel pitch 4mm Utilizing Sum driver IC to reach high refresh frequency and high grey grade;

3, Large viewing angle at 140 degree horizontal and vertical;

4, P4 LED display screens is of high resolution for indoor rental events that require high quality presentation and its cost is being lower for large size indoor LED screens use;

5, P4 indoor full color LED video display uniform in brightness and color;

6, Full color SMD2121 P4 LED screens is utilizing full black color LED chips;



Church Indoor P4 Advertising Led Display with SMD2020 Lisn control 0Church Indoor P4 Advertising Led Display with SMD2020 Lisn control 1Church Indoor P4 Advertising Led Display with SMD2020 Lisn control 2Church Indoor P4 Advertising Led Display with SMD2020 Lisn control 3
