Indoor P3.75 LED Screens Advertising / SMD2121 Indoor Full Color LED Video Boards

Indoor P3.75 LED Screens Advertising / SMD2121 Indoor Full Color LED Video Boards

Indoor P3.75 LED Screens Advertising / SMD2121 Indoor Full Color LED Video Boards
Indoor P3.75 LED Screens Advertising / SMD2121 Indoor Full Color LED Video Boards Indoor P3.75 LED Screens Advertising / SMD2121 Indoor Full Color LED Video Boards Indoor P3.75 LED Screens Advertising / SMD2121 Indoor Full Color LED Video Boards Indoor P3.75 LED Screens Advertising / SMD2121 Indoor Full Color LED Video Boards

Large Image :  Indoor P3.75 LED Screens Advertising / SMD2121 Indoor Full Color LED Video Boards

Product Details:
Place of Origin: China
Brand Name: YUCHIP
Certification: CE,ROHS,FCC,EMC
Model Number: IF-3.75S
Payment & Shipping Terms:
Minimum Order Quantity: 1sqm
Price: Negotiable
Packaging Details: Flight Case,Wooden Case,Strong Carton Box
Delivery Time: 15-20 Working Days
Payment Terms: T/T
Supply Ability: 5000㎡/Month
Detailed Product Description
High Light:

led video display board

,

commercial led display

Indoor P3.75 LED Screens Advertising / SMD2121 Indoor Full Color LED Video Boards





Quick Detail:





1. Full black color LEDs;

2. LED Source: SMD2121;

3. LED Module Size: 240mm x 240mm;

4. LED Cabinet Size: 480mm x 480mm x 65cm;
5. Woring voltage110V / 220V ;
6. Working temperature: -30 degree -- +60 degree









Description:





1, Indoor P3.75 LED Screens Advertising is easy handling: With ultra light weight and fast lockers features, the LED cabinet can be easily assembled and dismantled by one single person;

2, P3.75 HD indoor full color LED screens advertising ultra light weight: Utilizing extrusion aluminum LED cabinets;

3, P3.75 LED video walls is of stable quality: extrusion aluminum LED display is of high quality for frequent movement from one site to next;

4, Indoor advertising LED screens is ultra slim: Rental LED display is designed at 65mm thickness;

5, Fast and easy assembly: 4 set fast lockers equipped on each LED cabinet for seamless connection between cabinets;

6, High resolution: P3.75 is being widely choose for indoor rental LED Screens project because of its high resolution;







Applications:



Concert rental LED display

Entertainment events LED screen

Stadium rental LED wall

Fash show stage LED display

Car exhibition LED display

Rental commercial LED display

Airport Full Color Indoor LED displays
Train station Indoor Full Color LED Displays
Entertainment Bar Indoor Full Color LED Screen
Stadium Indoor Full Color LED Display
Museum Full Color Indoor LED display
Car exhibition LED display
Conference room Indoor Full Color LED Video Display
Shopping Mall Indoor Full Color LED display









Specifications :



LED MODULE PARAMETER
Pixel pitch (mm) 3.75
Pixel configuration 3 in 1
Encapsulation SMD2121
Colors matches 6:3:1
Module resolution (pixels) 64 x 64
Module pixel 4096
Module size (mm) 240 x 240
LED CABINET SPECIFICATION
Cabinet size (mm) 480 x 480 x 65
Cabinet resolution (pixels) 128 x 128
Cabinet pixels (pixels) 16384
Cabinet material Extrusion Aluminum
Cabinet weight (kg) 6.5kg
LED DISPLAY SPECIFICATION
Pixel density(pixel/m2) 71111
Brightness(cd/m2) ≥1500 (adjustable)
Brightness adjusted 100 grade by software or by Auto-optic induced
View angle Horizontal 140°; Vertical 140°
Best viewing distance (m) ≥3m
Communication distance(m) <100meter by Internet Cable(without Relay; Multi mode fiber cable < 500m;
Single mode fiber cable < 20km
Display work method 1/16 Scan
LED driving method Constant driving current
Color contrast ratio 4000:1
Gray Grade 16bit
Display Color 439, 804, 651, 110
Refresh Frequency (Hz) ≥1000
Picture display method Intellective control technology , test-itself technology , correct technology,
Synchronization Control
Input signal DVI (S-VIDEO, CVBS, ,DP,HDMI,VGA, PAL/NTSC, etc.through Video processor
converting )
System operating WINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc.
Front/Rear IP Level IP43
Working temperature(ºC) -20~+60
Stored temperature (ºC) -30~+80
Operation humidity(RH) 0-95%
Display Lifetime(hours) 10 years or more( natural environment)
100000 hours( ideal environment)
Maintenance Rear side
Working Voltage AC110 / AC220V±10% 47~63HZ
Out of controlled dot ≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the
wave length are both >10% depart to the normal one)











Competitive advantages:





1, SMD2121 P3.75 LED video walls is of large viewing angle at 140 degree horizontal and vertical;

2, P3.75 LED screens high resolution for indoor rental events that require high quality presentation;

3, P3.75 SMD2121 LED video display screens contrast ratio up to 4000:1 to present the real color;

4, P3.75 LED displays boardsis utilizing full black color LED chips to present a pure and deep beautiful color;

5, Utilizing Sum driver IC to reach high refresh frequency and high grey grade;

6, 36 months warranty.
