Small Pixel pitch 6.25 mm stadium perimeter LED display advertising full color waterproof

Small Pixel pitch 6.25 mm stadium perimeter LED display advertising full color waterproof

Small Pixel pitch 6.25 mm stadium perimeter LED display advertising full color waterproof
Small Pixel pitch 6.25 mm stadium perimeter LED display advertising full color waterproof Small Pixel pitch 6.25 mm stadium perimeter LED display advertising full color waterproof

Large Image :  Small Pixel pitch 6.25 mm stadium perimeter LED display advertising full color waterproof

Product Details:
Place of Origin: China
Brand Name: BAKO
Certification: CE/ROHS/FCC/SGS
Model Number: BK-P6.25
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Wooden box or flight case
Delivery Time: 20 days after advanced payment
Payment Terms: T/T, Western Union
Supply Ability: 5,000 sqm per month
Detailed Product Description
Product Name: P6.25 Fixed Installation Outdoor Advertising LED Display Small Pitch For Outdoor Module Size: 250*250mm
Cabinet Size: 1000*1000 Mm Scanning: 1/10 Scan
Application: Outdoor Advertising Brightness: 7500 Nits
Cabinet Resolution: 160*160 Cabinet Type: Iron Fixed
High Light:

led screen advertising

,

led advertising billboards





P6.25 fixed  installation outdoor advertising LED display small pitch for outdoor ​





Specifications:



Unit module

Pixel pitch

6.25 mm

Pixel density(dots/sqm)

25600/sqm

LED encapsulation

SMD3535

Driving method

1/10

Module size(mm)

250*250mm

Resolution of module( dots)

40*40

Major technical parameters

Cabinet size

1000*1000mm

Brightness

7500cd/ ㎡

Refresh rate

>2000HZ

Color temperature

6500K

View angle(H/V)

160°/140°

Grey scale

16bit

Brightness adjustment

256 grade/ Manually/ Automatically

Working/ storage temperature

-20℃~50℃/ -30℃~60℃

Working/ storage humidity

10%~90% RH

Working voltage

AC220/110V 50Hz

Protect degree

IP65/IP54

MTBF

>5000h

Life span

100000h

Input Signal

AV, S-VIDEO, VGA, DVI, HDMI, SDI, DP

Operation system

Windows 7/XP

Control distance

cat-5 data cable:<100m, optical fiber<15km

























































Quick details:





modules: P6.25 SMD outdoor

module size: 250*250mm

cabinet size: 1000*1000mm

scanning: 1/10 scanning





Description:





1.  Energy saving: power consumption is a key factor for LED billboard. BAKO’s LED display is designed with low power consumption to help clients to save energy.


2. Big view angle: SMD view angle is bigger than DIP.Its view angle is 160°for horizontal and 110°for vertical.


3. Good waterproof protection: Front is IP65 and back is IP54. There is totally no problem for outdoor application.


4. Anti-low temperature: for very cold areas such as Russian market, we should pay special attention to the cold temperature. So we will use anti-low temperature power suppliers and special heat system to warm the display.


5. Good heat output system for high temperature: For hot ares, heat output system is specially important. Or else, the whole display will become hot and there will be dangerous. So we help clients to reduce current and also make add fans for screen.


6.  Good color uniformity: Since 3 LED chips are encapsulated in one lamp, SMD color uniformity is much better than DIP so the showing effect is perfect.


7. High brightness: For outdoor application, brightness is important, especially if the LED display faces the sun directly. BAKO’s outdoor display brightness can be above 7500 nits, completely ensure the requirement for outdoor application.


8. Adjustable brightness: In the daytime, brightness should be high. But in the evening, it should be reduced for traffic safety. BAKO’s LED display can make the brightness adjusted automatically. Also, this method can help to save much energy.



9. Fast delievery time: BAKO has 6 high speed SMT lines. We always have product in stock.





Competitive Advantage:





1) small pitch for outdoor application

2) clear image

3) fast delievery

4) full solution provider
