Product Details:
Payment & Shipping Terms:
|
| Led Type: | SMD2525 | Module Resolution: | W 32 X H 32 Dots |
|---|---|---|---|
| Driver Mode: | 1/8 Scan | Brightness: | ≥465 CD/sq.ft |
| Protection: | IP65 | Life Time: | ≥100000hrs |
| High Light: | taxi LED screen,taxi LED sign |
||
Taxi Ad Agency Taxi Cab Advertising with P5 Taximedia LED Screen
Quick Viewing:
W 192 x H 64 dots, W 37.80 x H 12.60 inch each sides;
IP65 protection degree, waterproof and weatherproof;
High definition with 0.20inch (5mm) pixel pitch, 3i716 dots per square feet;
High brightness with 465CD per square feet, could be seen in direct sunshine;
Horizontal and vertical 120 degree Plus larger viewing angle than taxi LCD screens;
Less than 50LB (22kg) each set, ultra-thin and light weight design;
FCC/CE/TUV/ETL/RoHS certificated, both Europe and North America are satisfied;
It has a long lifetime of 100000 hours;
It can work under -40F–140F (-40-60℃) /5%-95%RH(non-condensing).
Detailed Description:
Taxi cab advertising is the main business of a taxi ad agency. Currently, P5 Taximedia LED screen is applied to show dynamic advertising contents. As the taxi led display is designed with 5500nits brightness, the contents on it are crystal clear and vivid, no matter they are photos are videos.
Ph5 outdoor taxi top full color led sign display system is installed on taxi top with led sign technology, equipped with wireless advertising public equipped, as high density pixels led screen have to be with blanking technology to ensure a perfect image, rather than a cheap regular viewing performance, now replacing the single color taxi top led sign.
- Very high contrast rate and a full color 16 bits grey scale;
- Lower energy consumption, lower heat dissipation and eco-friendly products;
- Wide viewing angels and high brightness for a long viewing distance and enlarge viewing scale;
- Anti-UV & good quality modules to ensure a good flatness of the whole led screen;
- High technology circuit design of good heat dissipation, long lifespan;
- High precise cabinets and modules to attain high flatness screen view;
Popular Application:
Taximedia led screen, taxi ad agency, taxi cab advertising;
Specifications:
| Item | Technical Parameters | |
| Screen model | OC-MT-P5SMD2525 | |
| R chip (wavelength range: 620-630nm, 5nm) | Brightness range: 500-900mcd | |
| G chip (wavelength range: 460-470nm, 4nm) | Brightness range: 1200-1500mcd | |
| B chip (Wavelength range: 520-530nm, 4nm) | Brightness range: 300-450mcd | |
| Module | Led configuration | SMD 3 IN 1: SMD2525/SMD3528 |
| Pixel pitch (mm) | 5mm(0.2 inch) | |
| Module resolution (W X H) | W 32 x H 32 dots | |
| Module dimension(W x H inch) | W 6.3 x H 6.3 x D 0.67 inch (W 160 × H 160 x D17 mm) |
|
| Cabinet | Module quantity(W × H) | W 6 × H 2, per side |
| Cabinet resolution(W × H) | W 192 × 64 dots, per side | |
| Cabinet dimension(W x H inch) | W 37.80 x H 12.60 inch per side (W 960 x H 320 mm per side) |
|
| Cabinet surface area(sq.ft) | 3.31 sq.ft / (0.31sq.m) per side | |
| Physical pixel density(dots/sq.ft) | 3716dots/sq.ft(40000dots/㎡) | |
| Brightness | ≥465CD/sq.ft (5000CD/㎡) | |
| Cabinet flatness(inch) | ≤0.08inch (0.2mm) | |
| Maintenance | Back-maintained | |
| Cabinet material | Aluminum | |
| Cabinet weight | ≤48.5lb (22kg) | |
| Optical parameters | Single-point brightness correction | available |
| Single-point color correction | available | |
| Color temperature(K) | 3200—9300 adjustable | |
| Horizontal viewing angle | 120° | |
| Viewing angle (Vertical) | 120° | |
| Brightness Uniformity | <3% | |
| Color uniformity | ≥97% | |
| Contrast ratio | 5000:1 | |
| Electrical parameters | Max power consumption | 580W per unit of taxi led screen |
| Average power consumption | 180-240W per unit of taxi screen | |
| Power supply | DC9-36V | |
| Security Features | GB4943/EN60950 | |
| Drive mode | Constant Current Driver, 1/8 scan | |
| Gray scale level | 10 bit | |
| Refresh rate(Hz) | ≥960 | |
| Processing | ≥14 bit | |
| Module comes with power failure | Save luminance, Color correction, module data | |
| Use parameter | Life time(hrs) | 100,000 hours |
| Operating temperature / humidity | -40F–140F (-40-60℃) /5%-95%RH(non-condensing) | |
| Storage temperature / humidity | -40F–140F (-40-60℃) /5%-95%RH(non-condensing) | |
| Certification | CCC/FCC/TUV/CE/ETL | |
