P7.62 High Resolution Indoor Stage And Advertising Rental LED Display

Large Image : P7.62 High Resolution Indoor Stage And Advertising Rental LED Display

Product Details:

Place of Origin:	CHINA
Brand Name:	HANTANG
Certification:	CE,RoHS,C-TICK,ISO.
Model Number:	HTGJ-IF7

Payment & Shipping Terms:

Minimum Order Quantity:	1 Square Meter/Square Meters module
Price:	US $ 1,300 - 2,300 / Square Meter
Packaging Details:	Plywood case/Flight cases etc.
Delivery Time:	10-15 working days.
Payment Terms:	30%before producing,the balance before shipping
Supply Ability:	3000sq.m/month.

Contact Now

Detailed Product Description

High Light:

rental led displays

led display signs

P7.62 High Resolution Indoor Stage And Advertising Rental LED Display

Pixel pitch:4mm,5mm,6mm,7.62mm,8mm,10mm,16mm...

Application :billboard,concerts , stage, events,stadium,advertising ,train station,shopping center,meeting screen ,airport ,mall...

Feature:

1, LED rental screen cabinet ultra-light, ultra-thin , simple structure, high compatibility , fast and quick installation, removal, saving time and labor costs.

2, LED rental screen cabinets , easy and convenient to install, low cost of installation; low -Consumption cabinet , save operating costs and reduce labor costs.

3, LED rental screen cabinet is designed with Die-cast aluminum , which is high strength , high toughness , high precision, easily deformed and highly wind resistance

4, High compatibility , the new structure designed to meet the lifting, stacking requirements to meet indoor and outdoor LED display requirements.

5, One cabinet can be installed in a few seconds with high precision, large area arbitrarily assembled .

6, No Screen noise , low power consumption, heat dissipation , high stability

7, According to customer requirements and site environment, tailored to the most suitable LED display rental solutions.

Specification:

Pitch(mm)	7.62
Pixel Constitute	1R1G1B
LED Chips--Opto+Silan	R:λd(625-630nm) G:λd(522.5-525nm) B:λd(467.5-470nm) R:(180-200mcd) G:(330-360mcd) G:(95-105mcd)
Pixel Density(dots/sqm)	17223
Module Size(mm)	245*122
Modules for 1 sqm(pcs)	33.6
Recommended Minimum Viewing Distance(m)	≥8
Viewing Angle(°)	V120, H140
Average Power Consumption	300W/sqm
Brightness (white balance)	≥1800cd/sqm
Refresh rate	2000Hz
Average NO failure time	5000 hours
Life span	100000 hours
Working temperature	-20 °C~+65°C
Driving Voltage	5VDC
Working Voltage	110 to 220 VDC
Driving mode	1/4
Display Function	Video, Animation, Graphics, other
Operating system	Windows (2000/XP/Vista)
Control distance	CAT5 cable:<100 m; Single fiber:<10 km
