7.62 mm Pixel Pitch Indoor LED Screen Rental for Theater , Hanging Beam

Product Details:

Payment & Shipping Terms:

Minimum Order Quantity:	negotiable
Price:	negotiable
Packaging Details:	Flight case
Delivery Time:	20 days after receiving the deposit
Payment Terms:	T/T, Western Union
Supply Ability:	2000sq.m/Month

Contact Now

Detailed Product Description

High Light:

waterproof led display

7.62 mm Pixel Pitch Indoor LED Screen Rental for Theater , Hanging Beam

Quick Detail:

1. SMD3528 LED type;

2. 1/8 scan constant current;

3. More than 1,200 nits/sq.m;

4. W 128 × H 128 pixels per cabinet;

5. W 8 × H 4 pcs cabinets in total;

6. 4 pcs power supplies each cabinet.

Detail Description:

The cabinet is W 976 × H 976 mm, with 105 mm thickness, about 30 kg/pc;

The project is composed with W 8 × H 4 pcs this size cabinets, with 7808 × 3904 mm display size;

There are 4 pcs power supplies in each cabinet.

Application:

This indoor LED screen rental is installed in theater for rental advertising.

Specifications:

Type	PH7.62
LED Composition	1R1G1B
LED Chip	EPISTAR
Resolution (dots/sq.m)	17,222
LED Module Pixel	W 32 × H 16
LED Module Size	W 244 × H 122 mm
Cabinet Dimension	W 976 × H 976 × T 105 mm
Cabinet Material	Aluminum cabinet with locks and hanging ring
Drive Method	1/8 scan constant current
Brightness	More than 1,200 nits/sq.m
Refresh Rate	More than 1200Hz
Out of Control Dot Rate	＜0.0001
Earth Leakage Current	＜2mA
MTBF	＞5,000 hours
Life Span	＞100,000 hours
Power Source	110V/60HZ and 220V/50HZ interchangeable
Package	Plywood case
Control Method	Synchronization control with video processor
Input Signal	DVI, COMPOSITE VIDEO, S-VIDEO, HDMI
