Rainproof P6 HD Flexible LED Screens, Operation Temperature - 40℃ - 60℃

Rainproof P6 HD Flexible LED Screens, Operation Temperature - 40℃ - 60℃

Rainproof P6 HD Flexible LED Screens, Operation Temperature - 40℃ - 60℃
Rainproof P6 HD Flexible LED Screens, Operation Temperature - 40℃ - 60℃

Large Image :  Rainproof P6 HD Flexible LED Screens, Operation Temperature - 40℃ - 60℃

Product Details:
Place of Origin: Shenzhen China
Brand Name: S&B
Certification: CE, RoHS, CCC, IP65
Model Number: SBO-P6
Warranty time:: 3 Years
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Packaging Details: Plywood case; flight case
Delivery Time: 10~20 days
Payment Terms: T/T
Supply Ability: 5000sq.meter / Month
Detailed Product Description
High Light:

flexible led display screen

,

flexible led curtain

Rainproof P6 HD Flexible LED Screens, Operation Temperature - 40℃ - 60℃





2011 Asian cup LED supplier



Application:



Commercial advertising, Stadium perimeter, mobile media, night club, entertainment events, business establishments, such as banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio, shopping malls, railways, airports, harbors, etc;



Characteristics:



1. CE&RoHS certificate

2. 36 months warranty and Life long free tech-support

3. Excellent contrast ratio, high resolution/high definition

4. Perect uniformity and no mosaic

5. Waterproof IP65

6. Light weight and easy to install

7. Available models: P10, P12, P16, P20, P25, P31.25, ect.



                SBO-P6 (Pitch 6mm outdoor full color)
Technique SMD
Pixel structure 1R1G1B 3in1
Pixel pitch 6mm
Pixel density 27,777 dots/㎡
Luminance 8,000 cd/㎡
Module dimension 288mm(W) * 288mm(H)/192mm(W) * 192mm(H)
Module resolution 48pixel(W) * 48pixelmm(H)/32pixel(W) * 32pixelmm(H)
Cabinet dimension 576 * 576mm/768 * 576mm
Cabinet resolution 96 * 96/128 * 96
Cabinet area 0.331/0.442 sq.meter
Optimal visual distance >6m
Visual angel 140 degree (H/V)
Max power consumption ≤1100w / ㎡
Average power consumption ≤600w / ㎡
Brightness adjustment Adjust according to the enviroment
brightness software (0%-100%adjustable)
Gray scale point by point 4096 gray gradelevels of
each color,16 bits γ correction avilable
Drive mode 1/8 dynamic scan, constant current
Frame frequency ≥60HZ
Refresh frequency ≥1000HZ
Input voltage AC 90~260 volts
Operation temperature ﹣40℃~ +60℃
Operation humidity 10%~90%
Input signal S-video, RF, RGB, Yuv, YC, composite…
Control system  DVI card + master control card + receiver card
MTBF >5000 hrs
Life span (50% brightness) 100,000 hrs
Malfunction dot rate 1/10000
Ingress protection rate IP65
Cabinet material Epoxy paint coated, aluminum / iron



Advantage:



1. High Contrast ratio: 4000:1

2. First-class LED chip

3. Clear vivid image quality

4. Long life time

5. Easy Installation & Operation

6. Convenient Servicing
