Product Details:
Payment & Shipping Terms:
|
| Pixel Pitch: | P8.93 / 10.42 / 17.85 / 20.83mm | LED Lamp: | 3in1 SMD 3535 |
|---|---|---|---|
| Brightness: | >4500 CD/sq.m | Refresh Rate: | >1200 Hz |
| Material: | Aluminum Die Casting | Base Height: | Adjustable |
| Panel Size: | 500*500*82mm (W*H*D) | Load Weight: | 2 Tons |
| High Light: | indoor LED screen,outdoor full color LED display |
||
Outdoor Waterproof P8 / P10 / P17 / P20 LED Video Floor High Brightness For Concerts
Main Feature:
High weight load-bearing
With rubber seal,suitable for outdoor application besides indoor.
With die casting materials, each panel is only 13kg, greatly save transportation cost.
Adjustable base support to make the screen surface extremely flat
Taking any panel from front side no need to remove any other tiles
Fan-less design make the screen very quiet. It’s very important used in TV studio, concerts, etc.
500×500mm (W×H), easy to calculate and assemble big screen within limited time.
Many pixel pitch displays optional such as 8.93mm, 10.42mm, 17.85mm , 20.83mm.
Application:
Perfectly used for outdoor/indoor stage, concert events, studio, clubs, sports,etc.
Specification:
| Concert Outdoor Floor LED Display | Unit | F-o8 | F-o10 | F-o17 | F-o20 |
|---|---|---|---|---|---|
| Pixel pitch | mm | 8.93 | 10.42 | 17.86 | 20.83 |
| Brightness | cd/㎡ | 4000/5000(H) | 3500/4500(H) | 4000/5000(H) | 3500/4500(H) |
| IP rating | ﹣ | Outdoor | |||
| Pixel density per tile | pixels | 56×56 | 48×48 | 28×28 | 24×24 |
| Pixel density | pixels/sqm | 12544 | 9216 | 3136 | 2304 |
| Viewing angle(H/V) | degree | 120/120 | 120/120 | 120/120 | 120/120 |
| Power consumption(max/ave) | W/tile | 180/60 | 150/50 | 180/60 | 150/50 |
| Size(W×H×D) | mm/tile | 500×500×82 | |||
| Material | lbs | Aluminum Die Casting | |||
| Weight | kg/tile | 13 | |||
| Weight | lbs | 29 | |||
| LED type | ﹣ | 3-in-1 SMD | |||
| Processing | bit/color | 14/16 | |||
| Colors | trillion | 4.39/281 | |||
| Refresh rate | Hz | 1200/4000 | |||
| Operating power | VAC,Hz | 220/110,50/60 | |||
| Serviceability | ﹣ | Front | |||
| Lifetime | hrs | 100,000 (@50% brightness) | |||
| Operating temperature | ℃ | ﹣30 ~50 | |||
| Operating humidity | RH | 10%~90% | |||
| Control System | ﹣ | Nova/Linsn/Dbstar | |||
| Source compatibility | ﹣ | AV,S-Video,HDMI,DVI,DP,VGA (with VP) | |||
| Certifications | ﹣ | CCC,CE,FCC,ETL | |||
