P10 Full Color 10000 Pixel Density Vivid Pictures Airport Outdoor LED Display

P10 Full Color 10000 Pixel Density Vivid Pictures Airport Outdoor LED Display

P10 Full Color 10000 Pixel Density Vivid Pictures Airport Outdoor LED Display
P10 Full Color 10000 Pixel Density Vivid Pictures Airport Outdoor LED Display

Large Image :  P10 Full Color 10000 Pixel Density Vivid Pictures Airport Outdoor LED Display

Product Details:
Place of Origin: CHINA
Brand Name: HANTANG
Certification: CE,ROHS,C-TICK,ISO
Model Number: HTGJ-OF10
Payment & Shipping Terms:
Minimum Order Quantity: N/A
Price: N/A
Packaging Details: Carton/Plywood case/Airfreight case
Delivery Time: 10~20days
Payment Terms: 30% before producing,the balance before shipping
Supply Ability: 3000sq.m/month
Detailed Product Description
High Light:

led outdoor displays

,

outdoor led sign

P10 Full Color 10000 Pixel Density Vivid Pictures Airport Outdoor LED Display



Application :billboard, concerts and and stage,  events, stadium, advertising , train station,  shopping center, meeting screen , airport , mall...



Features:

1,Using high -quality LED light tube , high brightness,  low light attenuation

2,100% polycarbonate ( the PC) as a suite of raw materials , with no distortion, no cracking, good toughness, simple splicing

3,LED screen Screen brightness is automatically adjusted to follow the external environment , does not produce light pollution

4 High refresh rate , scan mode screen is 2000HZ static screen  is more than 4000HZ

5,  Waterproof IP65





Technical Parameters of P10 full color outdoor LED display
Usage  Outdoor
Pitch(mm) 10
Pixel Constitute 1R1G1B
LED--Opto+Silan R:λd(625-630nm) G:λd(522.5-525nm) B:λd(467.5-470nm) R:Ⅳ(450-500mcd) G:Ⅳ(1600-1800mcd) G:Ⅳ(350-400mcd)
Pixel Density(dots/㎡) 10000
Module Size(mm) 160*160
Module Resolution 16*16
Recommended Minimum Viewing Distance(m) >=10
Viewing Angle(°C) V60, H120
Average Power Consumption 200W/㎡
Brightness (white balance) 7000cd/㎡
Size of cabinet(mm) 640*640*120
Weight of cabinet 60kg/㎡
Cabinet pixels(dot) 64*64
Frame frequency ≥60Hz
Refresh rate ≥2000Hz
Grey color ≥16.7M
Brightness adjustment 256 grade manual, 8 grade automatic
Average NO failure time 5000 hours
Life span 100000 hours
Working temperature -30 °C ~+60°C
Driving Voltage 5VDC
Working Voltage 110 to 220VDC
Scan Mode   1/4
Display Function Video, Animation, Graphics, other
Operating system Windows (2000/XP/Vista)
Control distance CAT5 cable:<100 m; Single fiber:<10 km
