Dustproof telecommunication Advertising LED Display Signs 7500 nit brightness

Large Image : Dustproof telecommunication Advertising LED Display Signs 7500 nit brightness

Product Details:

Place of Origin:	Shenzhen ,China
Brand Name:	LanGao
Certification:	CE/ROHS/FCC/UL/ISO/3C
Model Number:	LGP14

Payment & Shipping Terms:

Minimum Order Quantity:	1sqm. / 1 piece
Packaging Details:	Plywood or Flight Case
Delivery Time:	10-20 days
Payment Terms:	T/T ,L/C ,Paypal or

Contact Now

Detailed Product Description

Usage:	Outdoor	Tube Chip Color:	Full Color
Display Function:	Video	Pixels:	14mm
Brightness:	6000 To 8000cd/sqm	Protection Leve:	IP65
Led Chip:	Epistar/Slian	RGB:	2R1G1B / 1R1G1B
High Light:	led screen advertising , led display board for advertising

Waterproof and dustproof telecommunication Advertising LED Display Signs 7500 nit brightness

Advertising LED Display

1. Wide application field: advertising LED display, stadium perimeter LED display, mobile led display for mobile media, shopping mall LED display for logo showing, bank & stock exchange LED display for rates showing, train & bus station, airport, telecommunication LED screen system for information showing and instruction, stage performances and so on.
2. High Contrast and Frequency: 4000:1 and 5000HZ, which is a very high level to ensure a vivid image of our LED screen system.
3. Good quality LED chip: Supplied by Nichia, Cotco cree,Toyota,Silan.Optec,& other high strictly selected LED chip to ensure the long life time and high brightness of our LED screen system.
4. Very high quality and Clear vivid image quality: even in direct, full-on sunlight to ensure you attracts more audience to get short ROI of your LED screen's investment.
5. High Brightness of LED Display: 7500-nit brightness(for outdoor full color)(more than 2000 nits brightness for indoor full color) capacity throughout product lifetime of the LED display.
6. Easy Installation & Using : easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED screen system.

	Specification	PH14
1	Pitch	14mm
2	Module Resolution	16×8=128 (dot)
3	Module Size	224mm ×112mm
4	Module Quantity/cabinet	24(Pcs)
5	Cabinet Size	896mm×672mm
6	Resolution/cabinet	64×48(dot)
7	Density	5102(dot/s.q.m)
8	LED Driving method	Constant driving / 1/2 Scan
9	LED Standard	DIP546
10	Viewing Angle (H/V)	H:100±5°V:45°
11	Brightness	≥7000CD/s.q.m
12	The Optimal viewing distance	15-200m
13	Display Colors	687(million)
14	Pixel configuration	1R1G1B
15	Protection Degree	65(IP)
16	Power	(Max.Consumption): True pixels:1000 W/s.q.m
16	Power	(Average Power): True pixels:450 W/s.q.m
17	Control mode	Video Sync
18	Display Mode	(Max)1024×768/1280×1024
19	LED Parametres	(R):λd (619~624nm)IV: (460~510mcd)
		(G):λd (520~524.5nm)IV: (2000~2300mcd)
		(B):λd (468.5~472.5nm)IV:(490~540mcd)
20	Rate	≥300Hz
21	Communication	1000M Cats(≤120M)/Fiber optical (10.000m)

Features:

1) Reliable quality, advanced and mature technology, compliant with industrial
standards and technology developing trend
3) Good heat emission, water proof and stable performance
4) Audio and video interface of the system can offer vivid, complete and high
quality LED display to TV broadcasting signal
5) High resolution and definition of screen image, clear and non-flash screen
6) Supports video and radio frequency input, special structure can be freely
assembled
7) Widely used in stadium, bank, restaurant, station, shopping center,
government, schools, entertainment, and enterprise
