High Brightness LED Display Rental waterproof LED screen RGB SMD 3-in-1

Large Image : High Brightness LED Display Rental waterproof LED screen RGB SMD 3-in-1

Product Details:

Place of Origin:	Shenzhen ,China
Brand Name:	LanGao
Certification:	CE/ROHS/FCC/UL/ISO/3C
Model Number:	LGP5.33

Payment & Shipping Terms:

Minimum Order Quantity:	1sqm. / 1 piece
Packaging Details:	Plywood or Flight Case
Delivery Time:	10-20 days
Payment Terms:	T/T ,L/C ,Paypal or

Contact Now

Detailed Product Description

Usage:	Outdoor	Tube Chip Color:	Full Color
Display Function:	Video	Pixels:	5.33mm
Brightness:	6000 To 8000cd/sqm	Protection Level:	IP65
High Light:	hire led screen , led screen rental

RGB Ultra Slim Full color p5.33mm Rental LED display solutions for concert, stage and events

1. SMD3-in-1 technology is used for indoor LED Display
2. Wide view angle: 140 in horizontal and 140 in vertical.
3. Special design and advanced SMT technology improves the heat dissipation.
4, With high refresh rate controller, guarantee that no scan line when taking photos.
5. Regular shape and special shape(such as curve, round) can be designed.
6. Easy for assembling and connection with the connector added.
7, High color uniformity and clear image can bring you a vivid audio visual effect.
8. Both front access and rear access are available.

P5.33 indoor full color LED display
1	Pixel Information	Pixel Pitch	5.33mm
		Pixel Density	35,200dots/m²
		Pixel Configuration	1R1G1B
2	Viewing	Brightness	≥1800 CD/m²
		View Angle	140°/140°
		Optimum Viewing Distance	>5m
		Gray Level	RGB/8192/14bit
3	Power Supply	Working Voltage	110V~±15% or 230V~±15%
		Max Power Consumption	900W/m²
4	Ambient Conditions	Operating Temperature	-20°C~+60°C
		Operating Humidity	35%-85%
5	Processing	Driving Method	1/8scan, Constant Current
		Refresh Rates	≥800Hz
		Signal Input	RF,S-VIDEO,RGB,RGBTV,YUT,YC,COMPISITION
		Control System	Sending card + Receiving card + Hub card +PCTV Non-liner card + Muti-funcational card(Optional) + Video processor(Optional) + Fiber Transmitter (Optional)
6	Cabinet	Cabinet thickness	< 8cm	or Designed by requirements
		Cabinet weight	< 10kg/cabinet
		Cabinet size	Normal 640 x 640mm
		Cabinet material	Aluminum alloy or Iron, Steel
7	Others	Life Span	>100,000hours
		Blind Spot Rate	<0.00001
		LED encapsulation	SMD3528
		Color Temperature/contrast	Brightness and contrast of red, green and blue can be adjusted by software.
		Image Processing	Video denoising, rapid motion compensation, edge sharpening, edge smoothing
			Color coordinate conversation & control, grey scale transformation etc
		Brightness uniformity	Ratio of min pixel brightness/ max pixel<0.9 (when each color reaches its highest brightness)
		Effective control distance	Cat-5<100M, Muti-mode fiber: <500M; single- mode fiber<20Km

Product features

1) SMD3-in-1 technology is used for indoor LED Display.
2) Wide view angle: 140 in horizontal and 140 in vertical.
3) Special design and advanced SMT technology improves the heat dissipation.
4) with high refresh rate controller, guarantee that no scan line when taking photos.
5) Regular shape and special shape (such as curve, round) can be designed.
6) Easy for assembling and connection with the connector added.
7) High color uniformity and clear image can bring you a vivid audio visual effect.
8) Both front access and rear access are available.
9) Items: BESD-IFP4, BESD-IFP5, BESD-IFP5.33,BESD-IFP6, BESD-IFP7.62, BESD-IFP8, BESD-IFP10

Display Image Performance

1. wide view angle DIP/SMD LED is used for improving the view areas,meanwhile,make the LED display more smoothly.
2. High brightness and waterproof DIP/SMD LED is used for outdoor,and low brightness SMD LED for indoor.
3. High conformity of color and brightness makes the color of the display images more vivid.
4. High contrast ratio and high refresh rate technology makes the LED display peiformed well without any timelapse. 4.High contrast ratio and high refresh rate technology makes the LED display peiformed well without any timelapse.
5. Each specified LED cabinet can be guaranteed with the same brightness and color in different orders.This calibration technology is helpful for rental companies to extend the display as they like.
6. Item:BESD-IFP4, BESD-IFP5, BESD-IFP6, BESD-IFP7.62, BESD-IFP8, BESD-IFP10, BESD-OFP10,BESD-OFP12,BESD-OFP12.5,BESD-OFP16,BESD-OFP20,BESD-OFP25etc.
