Restaurant 46 Inch Wall Mounted Photos Display , LED Menu Board

Restaurant 46 Inch Wall Mounted Photos Display , LED Menu Board

Restaurant 46 Inch Wall Mounted Photos Display , LED Menu Board
Restaurant 46 Inch Wall Mounted Photos Display , LED Menu Board Restaurant 46 Inch Wall Mounted Photos Display , LED Menu Board Restaurant 46 Inch Wall Mounted Photos Display , LED Menu Board Restaurant 46 Inch Wall Mounted Photos Display , LED Menu Board

Large Image :  Restaurant 46 Inch Wall Mounted Photos Display , LED Menu Board

Product Details:
Place of Origin: China
Brand Name: Weiwen
Certification: CE,ROHS, FCC,C-tick,BV,GMC
Model Number: WW-WN-4608
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: negotiation
Packaging Details: 46" in wooden box ,size 130*24.5*97CM,80kg.
Delivery Time: 7-25 days
Payment Terms: 30% or 50% deposit,balance before shipping
Supply Ability: 5000PCS/month
Detailed Product Description
Screen Brand: AUO/SAMSUNG/CMO Screen Level: A + Grade
Speaker: Built In 2 Speakers Multi Screen: Yes
Video Formart: MPEG1、MPEG2、MPEG4、H.264、WMV、MKV、TS、flv Audio Format: MP3
Photo Format: JPG、JPEG、BMP、PNG、GIF Network: Lan,wifi,3g
High Light:

advertising digital signage

,

digital signage displays

Restaurant 46 Inch Wall Mounted Photos Display , LED Menu Board


Quick Detail:

  • This is designed based on B/S structure and distributed network management technologies, providing a perfect cross-platform solution. The system is deployed on Windows or Linux platform, and can work well with X86, Android and embedded terminals, with integrated management of display terminals like ad displays, LED full color displays, LCD splicing walls and ordinary LCD televisions.
  • For a widespread project, it is advised to use CDMS to compile programs and distribute contents to players via the network of WAN, LAN, VPN, WiFi or 3G. With rich remote management capabilities, CDMS is especially suitable for large and super-large scale network deployment, and can be easily scale as your business grows. Now it has widely used in the fields of media, finance, communications, transportation, catering, hotels and enterprises.



Description:


  1. Image, video, music, RSS, slide, interactivity, web, text are all supported.
  2. LOGO, instant messages, real-time date/time/week can be displayed.
  3. Support background image and background color.
  4. Support full screen and customized multi-zone presentation as you wish.
  5. Drag and drop editor makes content editing intuitive.
  6. Such slide features as IMP, music synchronization and background music are substitutes for the traditional light boxes and posters.
  7. The concise program publish interface allows you to arrange contents and their playback time, sequence, frequency and location easily.
  8. With intelligent scheduling, contents can be played on a loop, at a certain time or idle hours, or as instant break-ins.
  9. You can have your program published immediately or at your specified date and time.
  10. Contents can be updated remotely, or imported or read directly from a USB disk on site.
  11. Program previews and multi checks ensure information delivery correct and accurate.
  12. Owing to flexible classification management mechanism, players can be managed in organizations and groups, users can be granted different permissions.
  13. Advertiser details, related contents, price strategies and playback logs are all within your reach for ease of client management.
  14. Breakpoint resume, time download and bandwidth control help to make use of network resources more effectively.
  15. The powerful feature of time on/off in multiple periods achieves unattended operation.
  16. Player operations such as adjusting playback volume, changing display screen, reboot, and hibernation can be completed remotely with just one click.
  17. You are allowed to oversee players remotely in real time, and will be provided with various running and operation reports.
  18. Health monitoring technique is employed to give failure alert in time.
  19. Remote upgrade and intelligent DNS make operation and maintenance more convenient.
  20. Deployments across WAN/LAN/VPN/WiFi/3G network, and different regions are supported.
  21. Customizable for your specific needs and will easily scale as your business grows


Specifications:



HARDWARE

CPU

Dual core ARM Cortex A9

GPU

Quad core ARM Mali-400 MP

Standard frequency

1.5GHz(Max1.6GHz)

System RAM

DDR3 1Gbyte,brand:HYNIX/SAMSUNG

System ROM

NAND FLASH 4Gbyte,brand:HYNIX/SAMSUNG

Storage

TF/USB

Decoding resolution

MAX. 1080P

MAIN FUCTION

O/S

Android 4.2.2

Playback function

Start to play automatically; the display terminal work time according to a predetermined schedule and program to play multimedia content, according to a preset template screen graphic display relevant information to support the playback modes include:

1) spots

2) Specify Time Play

3) Cycle Play

4) Gasket Play

Network Support

Support 10 / 100M Ethernet

Support WIFI (150Mbps)

Scalable 3G module

Picture stretch

The picture is automatically displayed on the area stretching and tiled display, the terminal supports decoding maximum picture resolution is 1080p.

Remote Control Terminal

Support for remote control commands sent by the server parsing and processing, including: news spots, restart the terminal, sleep, wake up, forced shutdown, timer switch, set the remote online upgrade volume, application, set the terminal download speed limit.

SUPPORTED FORMAT

Video decoding

Real-time video decoding, support for MPEG-1, MPEG-2, MPEG-4, H.263, H.264, AVS, VC-1, RV, VP6 / VP8, Sorenson Spark, MVC decoding

Decoding resolution

Supports up to 1080P @ 60fps

Video Coding

H.264,MVC, VP8

Encoding resolution

Supports up to 1080P @ 30fps

Photo format

JPG,JPEG,BMP,PNG,GIF

Scrolling text format

TXT(doc)

Video format

MPEG1,MPEG2,MPEG4,H.264,WMV,MKV,TS,flv

Audio format

MP3

CONNECTIONS

USB 2.0 Port

1 x USB Host, 1 x USB OTG

3G module

A PCIE slot (supporting a phone deck)

A USB interface

LVDS Interface

1 x can directly drive 15 ~ 100 inch LCD screen, 50/60Hz

Audio input

3.5mm Phone Jack

Audio output

CLASS-D stereo amplifier output , 8Ω 2x10W (12V)

Video input

VGA×1,HDMI×1

Expansion Interface

A serial port

An SPI port

1 Camera Input

A USB touch screen interface

Etc.

RTC real time clock, Timer switch, System and screen program upgrade via network and USB

ELECTRICAL

PWR Input

DC 12V/5A (Power On/Off)

PWR Consumption

Not more than 5W (without Speaker, LCD, Backlight Inverter, USB Device)

ENVIRONMENT

Operating Temperature

0℃ to 40℃

Operation Humidity

10% to 90% (No condensation)

Storage Temperature

-40℃ to 70℃, (Recommended = 5℃ to 35℃)




Applications:

1. Business Organizations: supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy.
2. Financial Organizations: Banks, negotiable securities, funds, insurance companies, pawnshops;
3. Non-profit Organizations:Telecommunications, post offices, hospital, schools;
4. Public Places: subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums, convention centers, ticket agencies, HR market, lottery centers;
5. Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms, property brokers;
6. Entertainments:Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course.


Our advantage:

1. All the materials are all tested, quality assuranced;We select only branded screen,and all are A grade standard or even A + grade standard panel.
2. We are factory,we have our own production line, we produce independently from producing shells to the whole production process, more convenient and comprehensive for quality controlling.
3. We could customize and do OEM/ODM service for our customers, according to customers’ design and requirements.
4. We have a fully professional team, combining designing, processing, production, can be relatively rapidly transfer customer ideas into products.
5. Our first-class service team, able to "we worry what customer worry, think what customers think," and to help all customers to solve all the worries.
